Page 1: User Manual
TT1-MI Tangential tonearm User manual Made in Germany clearaudio electronic ® GmbH Spardorfer Str. 150 • D-91054 Erlangen • Tel. +49 9131 40300100 • FAX + 49 9131 40300119 www.clearaudio.de • www.analogshop.de • info@clearaudio.de ©clearaudio electronic GmbH Version: 1.7_12.10.2016_E... - Page 2 StatementTT1 We wish you much pleasure with your new Clearaudio tangential tonearm. Clearaudio electronic GmbH Warnings Do not expose the equipment to rain or moisture.
-
Page 3: Table Of Contents
3. Front- and rear view of assembled tonearm 4. Assembly and operation TT1-MI Master Innovation 5. Mounting the on the turntable 8 - 10 6. Cartridge pre-adjustment / adjustment 10 - 12 7. Technical data 8. Special notes Warranty © clearaudio electronic GmbH 2016 Page 3... -
Page 4: List Of Components
Cartridge alignment gauge Armwand Cartridge mounting screws Bag of hex wrench: 1.5/8mm Main counterweights 2x large hex socket headed bolts 2x spacer discs White gloves User manual, warranty card and return delivery note (not shown) Page 4 © clearaudio electronic GmbH 2016... -
Page 5: Package Overview
The TT1–MI is packed in a special foam packaging and comes almost completely assembled. Pic. 2: Package overview Please note: The armwand is packed separately and need to be installed. Pic. 3: Armwand Additional parts, accessories and tools are also packed separately. © clearaudio electronic GmbH 2016 Page 5... -
Page 6: Front And Rear View Of Assembled
Rear view Tonearm cable ground screw Tonearm cable holder Cueing lever Cueing lift mechanism Tonearm cable holder Precision glass tube for bearing carriage Mounting bolt Pic. 4: Front and rear view Page 6 © clearaudio electronic GmbH 2016... -
Page 7: Assembly And Operation
Please note, you may need to remove the previous discs/cylinders first. TT1-MI Please use only the spacer discs provided, as they are specifically height-matched for the tonearm. Master Innovation Pic. 5: Placing the stainless steel spacer discs onto the turntable © clearaudio electronic GmbH 2016 Page 7... -
Page 8: Mounting The Tt1-Mi
Please note: Always hold the tonearm in place while tightening the mounting bolts. Pic. 5: Placing the tonearm chassis on the spacer discs 8 mm hex wrench Pic. 6: Tightening the mounting bolts Page 8 © clearaudio electronic GmbH 2016... - Page 9 Remove the rubber band which is used as transportation lock. Afterwards loosen the screws from the aluminum block and remove the second transportation lock. Pic. 7: Pre-mounted bearing carriage and glass tube with transportation lock Pic. 8: Mounting of the armwand Page 9 © clearaudio electronic GmbH 2016...
-
Page 10: Cartridge Pre-Adjustment / Adjustment
Mount the armwand to the bearing carriage with the aluminum block and the two screws again. Pic. 9: Mounted armwand 6. Cartridge pre-adjustment / adjustment First mount the cartridge into the headshell using the two headshell screws provided (Page 4 No. 7). Pic. 10: Mounting of the cartridge Page 10 © clearaudio electronic GmbH 2016... - Page 11 Pic. 11: Counterweight adjustment Turn the two knobs (wheels) of the precision VTA adjustment on top of the tonearm until the armwand axis is parallel to the record surface. Pic. 12: Cartridge pre-adjustments Page 11 © clearaudio electronic GmbH 2016...
- Page 12 Attention: Before first use or after a long period of storage, please move the cueing lift up and down approximately 4-5 times so that the oil inside can flow allowing the cueing lift to operate smoothly. Page 12 © clearaudio electronic GmbH 2016...
-
Page 13: Technical Data
Warranty: 5 years* * Only if the warranty card is filled out correctly and sent back within 14 days to Clearaudio Clearaudio electronic is not responsible for any typographical errors in descriptions. Technical specifications are subject to change or improvement without prior notice. Product availability will be as long as stock lasts. -
Page 14: Special Notes
Otherwise serious damage could occur. 8.3 Service If any servicing or repair of a Clearaudio product is necessary, please first contact your dealer or distributor. Alternatively contact Clearaudio directly and we will advise you of your nearest service location. - Page 15 RETAIN YOUR PURCHASE RECEIPT Your purchase receipt is your permanent record of a valuable purchase. It should be kept in a safe place to be referred to as necessary for insurance purposes or when corresponding with clearaudio. IMPORTANT When seeking warranty service, it is the responsibility of the consumer to establish proof and date of purchase. Your purchase receipt or invoice is adequate for such proof.
