NOTE:
•
Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
•
-XX, -X mean standardized parts, so they
may have some difference from the original
one.
•
Items marked " * " are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
•
RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
Ref. No.
Part No.
Description
A-4541-780-A AMP BOARD, COMPLETE
*
********************
3-265-148-01 SHEET (L), INSULATING
3-265-149-01 SHEET (S), INSULATING
< CAPACITOR >
C1
1-165-176-11 CERAMIC CHIP
C2
1-165-176-11 CERAMIC CHIP
C3
1-126-193-11 ELECT
C4
1-126-193-11 ELECT
C5
1-126-209-11 ELECT CHIP
C6
1-126-209-11 ELECT CHIP
C7
1-117-681-11 ELECT CHIP
C8
1-117-681-11 ELECT CHIP
C9
1-117-681-11 ELECT CHIP
C10
1-117-681-11 ELECT CHIP
C11
1-126-209-11 ELECT CHIP
C12
1-126-209-11 ELECT CHIP
C13
1-117-681-11 ELECT CHIP
C14
1-117-681-11 ELECT CHIP
C15
1-125-837-91 CERAMIC CHIP
C16
1-125-837-91 CERAMIC CHIP
C17
1-125-837-91 CERAMIC CHIP
C18
1-125-837-91 CERAMIC CHIP
C19
1-107-826-11 CERAMIC CHIP
C20
1-107-826-11 CERAMIC CHIP
C21
1-124-779-00 ELECT CHIP
C22
1-126-208-21 ELECT CHIP
C23
1-126-925-91 ELECT
C24
1-125-891-11 CERAMIC CHIP
C25
1-125-891-11 CERAMIC CHIP
C101
1-162-964-11 CERAMIC CHIP
C102
1-162-964-11 CERAMIC CHIP
C103
1-162-964-11 CERAMIC CHIP
C104
1-162-964-11 CERAMIC CHIP
C105
1-162-964-11 CERAMIC CHIP
< DIODE >
D1
8-719-800-76 DIODE 1SS123-T1
< IC >
IC1
8-759-524-84 IC TEA2025D-013TR
IC2
8-759-524-84 IC TEA2025D-013TR
SECTION 6
ELECTRICAL PARTS LIST
•
CAPACITORS:
uF: µF
•
COILS
uH: µH
•
SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
•
Abbreviation
CND : Canadian model
JE
: Tourist model
•
Accessories are given in the last of this parts
list.
Remarks
Ref. No.
0.047uF
10.00% 16V
0.047uF
10.00% 16V
1uF
20%
50V
1uF
20%
50V
100uF
20.00% 4V
100uF
20.00% 4V
100uF
20.00% 16V
100uF
20.00% 16V
100uF
20.00% 16V
100uF
20.00% 16V
100uF
20.00% 4V
100uF
20.00% 4V
100uF
20.00% 16V
100uF
20.00% 16V
1uF
10%
6.3V
1uF
10%
6.3V
1uF
10%
6.3V
1uF
10%
6.3V
0.1uF
10.00% 16V
0.1uF
10.00% 16V
10uF
20%
16V
************************************************************
47uF
20.00% 4V
470uF
20.00% 10V
0.47uF
10.00% 10V
0.47uF
10.00% 10V
0.001uF
10%
50V
0.001uF
10%
50V
0.001uF
10%
50V
0.001uF
10%
50V
0.001uF
10%
50V
************************************************************
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Part No.
Description
< TRANSISTOR >
Q1
8-729-027-60 TRANSISTOR
Q2
8-729-027-60 TRANSISTOR
< RESISTOR >
R1
1-216-829-11 METAL CHIP
R2
1-216-829-11 METAL CHIP
R3
1-216-813-11 METAL CHIP
R4
1-216-813-11 METAL CHIP
R5
1-216-821-11 METAL CHIP
R6
1-216-821-11 METAL CHIP
R7
1-216-829-11 METAL CHIP
R8
1-216-829-11 METAL CHIP
R9
1-216-813-11 METAL CHIP
R10
1-216-813-11 METAL CHIP
R11
1-216-789-11 METAL CHIP
R12
1-216-789-11 METAL CHIP
R13
1-216-821-11 METAL CHIP
R14
1-216-821-11 METAL CHIP
R15
1-216-821-11 METAL CHIP
R16
1-216-833-11 METAL CHIP
R17
1-216-833-11 METAL CHIP
R21
1-216-829-11 METAL CHIP
R22
1-216-829-11 METAL CHIP
< SWITCH >
SW1
1-554-295-21 SWITCH, SLIDE (POWER)
JACK BOARD
**********
< CAPACITOR >
C106
1-162-964-11 CERAMIC CHIP
< DIODE >
D2
8-719-978-33 DIODE UDZSTE-176.8B
< JACK >
J1
1-568-907-21 ACK,DC(POLARITY UNIFIED TYPE)(DC IN)
RV1 (on AMP board)
*
Supply with a single article has not been carried out.
Please exchange by SUB ASSY, KNOB (VOLUME).
(Part No. X-3384-656-1)
SRS-T88
AMP
JACK
Remarks
DTC144TKA-T146
DTC144TKA-T146
4.7K
5%
1/16W
4.7K
5%
1/16W
220
5%
1/16W
220
5%
1/16W
1K
5%
1/16W
1K
5%
1/16W
4.7K
5%
1/16W
4.7K
5%
1/16W
220
5%
1/16W
220
5%
1/16W
2.2
5%
1/16W
2.2
5%
1/16W
1K
5%
1/16W
1K
5%
1/16W
1K
5%
1/16W
10K
5%
1/16W
10K
5%
1/16W
4.7K
5%
1/16W
4.7K
5%
1/16W
0.001uF
10%
50V
13
