Axis Video Server 241SA User Manual page 67

Item
Connectors
Casing
Processors and memory
Power
Operating conditions
Installation, management
and maintenance
Video access from Web
browser
Minimum Web browsing
requirements
System integration
support
Supported protocols
AXIS 241QA/AXIS 241SA - Technical specifications
Specification
• Analog composite video,
• NTSC/PAL autosensing inputs:
• AXIS 241QA: 4 BNC inputs
• AXIS 241SA: 1 BNC input and 1 BNC output: loop through or Y/C video input
• Ethernet 10BaseT/100BaseTX, RJ-45
• Terminal block:
4 alarm inputs,
4 alarm outputs,
RS-485/422 half duplex port,
Alternative power connection
• D-Sub for RS-232 port
• AXIS AXIS 241QA/AXIS 241SA: 3.5 mm jack for Mic in (max 54 mVpp) or Line in
(max 8.0 Vpp, mono),
• 3.5 mm jack for Line out (max 2.6 Vpp, mono) to active speaker
• Metal casing. Standalone, stackable or with brackets for wall or cage mount
• CPU: ETRAX 100LX 32bit
• Video processing and compression: ARTPEC-2
• RAM: 64MB (AXIS 241QA), 32 MB (AXIS 241SA)
• Flash: 8 MB
• Battery backed up by real-time clock
• 7 - 20 V DC, max 8 W
• 5 - 50 ºC (41 - 122 ºF)
• Humidity 20 - 80% RH (non-condensing)
• Installation tool on CD and web-based configuration
• Configuration backup and restore
• Firmware upgrades over HTTP or FTP, firmware available at www.axis.com
• Camera live view
• Sequence tour capability for up to 20 PTZ presets or other Axis video sources
• Customizable HTML pages
• Pentium III CPU 500 MHz or higher, or equivalent AMD128 MB RAM AGP graphic
card, Direct Draw, 32 MB RAM
• Windows XP, 2000, Server 2003, NT4.0*, ME* or 98*, DirectX 9.0 or later Internet
Explorer 5.x or later
• For other operating systems and browsers see www.axis.com/techsup
*Motion JPEG only
• Powerful API for software integration available at www.axis.com, including AXIS
VAPIX API, AXIS Media Control SDK, event trigger data in video stream, embedded
scripting and access to serial port peripherals over HTTP/TCP
• Watchdog secures continuous operation, can be monitored by other systems via
event notification
• Embedded operating system: Linux 2.6
• HTTP, HTTPS, SSL/TLS*, TCP, SNMPv1/v2cv/v3 (MIB-II), RTSP, RTP, UDP, IGMP, RTCP,
SMTP, FTP, DHCP, UPnP, ARP, DNS, DynDNS, SOCKS. More information on protocol
usage available at www.axis.com
* This product includes software developed by the Open SSL Project for use in the
Open SSL Toolkit.
67
