SCSI ID Settings
The following table identifies the various SCSI ID values and the jumper positions required to set them.
Drive ID
ID 0
ID 1
ID 2
ID 3
ID 4
ID 5
ID 6
ID 7
4 of 8
Atlas II
Jumper Settings
A0
A1
A2
OFF
OFF
OFF
ON
OFF
OFF
OFF
ON
OFF
ON
ON
OFF
OFF
OFF
ON
ON
OFF
ON
OFF
ON
ON
ON
ON
ON
