Quantum Atlas II Settings Manual page 2

Quantum hard disk drive mounting instructions

Advertisement

Termination Power (TP)
Enable termination power
Disable termination power
SCSI ID (A3, A2, A1, A0)
Set drive SCSI ID
Delay Spin (DS)
Enable spin delay
Disable spin delay
cStagger Spin
Enable spin stagger
Disable spin stagger
Write Protect
Enable W rite Protection
Disable W rite Protection
Jumper Locations
The Atlas II disk drive has two locations where user configurable jumpers are found. The primary jumper block (Front option
connector J3) for the Atlas II is found on the front edge of the disk drive printed circuit board. Using these jumper pins you
can establish the various drive configuration options. The second option jumper block is used to set the Atlas II termination
options. This jumper block is found on the printed circuit board at the rear of the drive and is near the SCSI cable connector.
2 of 8
Atlas II
Jumper Settings
SP jumper off
SP jumper on
WP jumper on
WP jumper off
TP jumper on
TP jumper off
See ID settings table below
SS jumper on
SS jumper off
