TCP/IP Setting
+========================+
| TCP/IP Setting
+========================+
[1].IPv4 Address:
[2].IPv4 Subnet Mask:
[3].IPv4 Gateway IP:
[4].IPv4 DNS or WINS IP:192.168.001.001
[5].DHCPv4 Client:
[6].IPv6 Address:
[7].IPv6 Prefix Length: 64
[8].IPv6 Gateway IP:
[9].IPv6 DNS IP:
[a].DHCPv6:
[b].Host Name(NetBIOS): INSIGHTPOWER
[c].System Contact:
[d].System Location:
[e].Auto-Negotiation:
[f].Speed:
[g].Duplex:
[i].Telnet Idle Time:
[0].Back To Previous Menu
Please Enter Your Choice =>
No. Item
[1] IPv4 Address
[2] IPv4 Subnet
Mask
[3] IPv4 Gateway IP The IPv4 gateway's IP address.
[4] IPv4 DNS or
WINS IP
[5] DHCPv4 Client
[6] IPv6 Address
[7] IPv6 Prefix
Length
[8] IPv6 Gateway IP The IPv6 gateway's IP address.
[9] IPv6 DNS IP
[a] DHCPv6
[b] Host Name
(NetBIOS)
|
192.168.001.100
255.255.255.000
192.168.001.254
Enable
fe80::230:abff:fe25:900
::
::
Enable
Enable
100M
Full
60 Seconds
Description
The IPv4 address.
The IPv4 subnet mask setting.
IPv4 Domain Name Server or
WINS IP.
Enable/ disable DHCPv4 protocol. Enable
The IPv6 address.
The IPv6 prefix length.
IPv6 Domain Name Server's IP
address.
Enable/ disable DHCPv6 protocol. Enable
The Host Name for the SNMP
IPv6.
1 7
Chapter 4 System Configurations
Default
192.168.001.100
255.255.255.000
192.168.001.254
192.168.001.001
INSIGHTPOWER
