Front and Rear Panels

The following figures show the Mantaray interfaces, connectors, and LED status indicators.
Figure 4
Component Video Out
(YPbPr, 3 RCA jacks)
Power
Composite Video Out
(CVBS, 1 RCA jack)
Figure 5
USB Host
(x4)
SD Card Slot
Mantaray Administrator's Guide, v1.0.3, Issue 01
Rear View
S/PDIF Audio Out
(RCA/coaxial)
2-Channel
Audio Out
(2 RCA jacks)
Side/Front View
VGA Out
HDMI Out
Reset switch
S/PDIF Audio Out
(TOSLINK optical)
Network Indicator
Status Indicators
IR Receiver
Introduction

Front and Rear Panels

Antenna
Ethernet
(RJ45)
Power/Standby
button
