IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR
USE YOUR LYNX 5 DRAWER CHEST.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
ASSEMBLY:
Assembly should be carried out with this item laying flat, not standing upright.
Assemble on a soft, clean surface to prevent damages.
To erase the numbers printed on the pieces, use the rubber into the accessories pack.
HEALTH & SAFETY:
DO NOT use this chest if any parts are missing, damaged or worn.
DO NOT use this chest unless all fixings are secured .
Always use on a level, even surface.
CARE & MAINTENANCE:
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the chest as this will damage the base.
Always lift the chest with two people to reposition.
Keep any sharp objects away from the chest.
Rev 05
ASSEMBLY INSTRUCTIONS
LYNX 5 DRAWER CHEST
www.birlea.com
Vendor: S000139
Page
1
of 5
Advertisement
Table of Contents
Related Manuals for Birlea LYNX 5
Summary of Contents for Birlea LYNX 5
- Page 1 ASSEMBLY INSTRUCTIONS LYNX 5 DRAWER CHEST IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR USE YOUR LYNX 5 DRAWER CHEST. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. ASSEMBLY: Assembly should be carried out with this item laying flat, not standing upright.
- Page 2 Vendor: S000139 Parts List Hardware List Part Descripion Part Descripion Top Panel 8 x 30mm Wooden Dowel Left Panel Plastic Cap Right Panel 3 x 14mm Screw Plinth 3.5 x 25mm Screw Drawer Front 4.5 x 45mm Screw Left Drawer Panel 10 x 10mm Tack Right Drawer Panel Simple Minifix Screw...
- Page 3 Vendor: S000139 Step 1: Attach the drawer runners (12) to the left panel (2) and right panel (3) using hadware part D. Insert hardware parts A and H into each side panel using a small mallet and screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim.
- Page 4 Vendor: S000139 Step 4: Attach the top panel (1) using hardware parts I then attach hardware parts K to the base using hardware part G. You will need to use a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 5: Connect the back panels (10) using the spine (14) and secure using hardware part G and a small mallet (not provided).
- Page 5 Then attach hardware part D to the item with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Birlea Furniture advise you use the wall straps provided to further enhance the safety of this product 1°...
