IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR
USE YOUR LYNX 3 DOOR ROBE WITH MIRROR.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
ASSEMBLY:
Assembly should be carried out with this item laying flat, not standing upright.
Assemble on a soft, clean surface to prevent damages.
To erase the numbers printed on the pieces, use the rubber into the accessories pack.
HEALTH & SAFETY:
DO NOT use this wardrobe if any parts are missing, damaged or worn.
DO NOT use this wardrobe unless all fixings are secured.
Always use on a level, even surface.
CARE & MAINTENANCE:
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the wardrobe as this will damage the base.
Always lift the wardrobe with two people to reposition.
Keep any sharp objects away from the wardrobe.
Rev 03
ASSEMBLY INSTRUCTIONS
LYNX 3 DOOR ROBE WITH MIRROR
www.birlea.com
Vendor: S000139
Page
1
of
6
Advertisement
Table of Contents
Related Manuals for Birlea LYNWD3WBK
Summary of Contents for Birlea LYNWD3WBK
- Page 1 Periodically check all screws & fixings to ensure they are secure. DO NOT push the wardrobe as this will damage the base. Always lift the wardrobe with two people to reposition. Keep any sharp objects away from the wardrobe. www.birlea.com Page Rev 03...
- Page 2 Vendor: S000139 Hardware List Part Descripion 8 x 30mm Wooden Dowel Simple Minifix Screw Parts List Cam Lock Part Descripion Top Panel Plastic Cap Shelf 8 x 50mm Wooden Dowel Base Panel 3.5 x 25mm Screw Plinth 3.5 x 20mm Screw Left Panel 3.5 x 14mm Screw Shelf Divider...
- Page 3 Vendor: S000139 Step 1: Prepare these parts for assembly using hardware parts A, B, E, G, H, I, J, K, L, M, N and O. You will need to use a small mallet and a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Page...
- Page 4 Vendor: S000139 Step 2: Attach the plinths (4) to the right panel (11) then attach the base panel (3) using hardware parts C and D with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 3: Attach the front support (7), back support (8) and shelf (2) using hardware parts C and D with a screwdriver (not provided).
- Page 5 Vendor: S000139 Step 4: Insert the hanging rail (15) then attach the left panel (5) using hardware parts C and D. Attach the shelf divider (6) using hardware parts C, D and P. You will need to use a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim.
- Page 6 Then attach hardware part H to the item with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Birlea Furniture advise you use the wall straps provided to further enhance the safety of this product. 1°...
