IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR
USE YOUR LYNX 3 DOOR 2 DRAWER ROBE.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
ASSEMBLY:
Assembly should be carried out with this item laying flat, not standing upright.
Assemble on a soft, clean surface to prevent damages.
To erase the numbers printed on the pieces, use the rubber into the accessories pack.
HEALTH & SAFETY:
DO NOT use this wardrobe if any parts are missing, damaged or worn.
DO NOT use this wardrobe unless all fixings are secured.
Always use on a level, even surface.
CARE & MAINTENANCE:
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the wardrobe as this will damage the base.
Always lift the wardrobe with two people to reposition.
Keep any sharp objects away from the wardrobe.
Rev 03
ASSEMBLY INSTRUCTIONS
LYNX 3 DOOR 2 DRAWER ROBE
www.birlea.com
Vendor: S000139
Page 1 of
9
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Birlea LYN3DCBLG
Summary of Contents for Birlea LYN3DCBLG
- Page 1 Periodically check all screws & fixings to ensure they are secure. DO NOT push the wardrobe as this will damage the base. Always lift the wardrobe with two people to reposition. Keep any sharp objects away from the wardrobe. www.birlea.com Page 1 of Rev 03...
- Page 2 Vendor: S000139 Hardware List Parts List Part Descripion 8 x 30mm Wooden Dowel Part Descripion Top Panel Simple Minifix Screw Shelf Cam Lock Base Panel Plastic Cap Plinth 8 x 50mm Wooden Dowel Left Panel 3.5 x 25mm Screw Shelf Divider 3.5 x 20mm Screw Drawer Cabinet - Right Panel 3.5 x 14mm Screw...
- Page 3 Vendor: S000139 Step 1: Prepare these parts for assembly using hardware parts A, B, E, G, H, I, J, K, L, M, N, O and R. You will need to use a small mallet and a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Page 3 of...
- Page 4 Vendor: S000139 Step 2: Attach the drawer cabinet right panel (7) and drawer cabinet left panel (13) to the base panel (3) using hardware part S and a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 3: Attach the base panel (3) and the plinths (4) to the right panel (8) using hardware parts C and D with a screwdriver (not provided).
- Page 5 Vendor: S000139 Step 4: Attach the drawer cabinet top panel (12) using harware parts P and C. Attach the front support (21) and back support (11) using hardware parts C and D. You will need to use a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim.
- Page 6 Vendor: S000139 Step 6: Secure the shelf (2) to the back support (11) and front support (21) using harware parts C,D, and P. Fix the shelf divider (6) to the shelf (2) using hardware parts C and D. You will need to use a screwdriver (not provided).
- Page 7 Vendor: S000139 Step 8: Connect two back panels (10) using the spine (22) then position all back panels. Attach the top panel (1) using hardware parts C and D. Insert the shelves (20) using hardware parts M and T. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Choose the desired height for shelf placement...
- Page 8 Vendor: S000139 Step 10: Attack the doors (9) and the mirrored door (19) then attach the handles (24) using hardware part F. You will need to use a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Horizontal Ajustment Depth Ajustment Vertical Ajustment...
-
Page 9: Additional Information
Then attach hardware part H to the item with a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Birlea Furniture advise you use the wall straps provided to further enhance the safety of this product. 1°...
