Summary of Contents for Black Box Sync SHM-NPR MP
Page 1
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com...
FCC INFORMATION FEDERAL COMMUNICATIONS COMMISSION INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart J of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference...
Page 3
SYNC SHM-NPR MP NORMAS OFICIALES MEXICANAS (NOM) ELECTRICAL SAFETY STATEMENT INSTRUCCIONES DE SEGURIDAD 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
Page 4
NOM STATEMENT 10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor como radiadores, registros de calor, estufas u otros aparatos (incluyendo amplificadores) que producen calor. 11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del tipo descrito en el instructivo de operación, o como se indique en el aparato.
Page 5
SYNC SHM-NPR MP TRADEMARKS USED IN THIS MANUAL Any trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.
SYNC SHM-NPR MP 1. Specifications Protocol — Synchronous Speed — 1200 to 19,200 bps Distance — Wire Gauge Speed (bps) 19,200 7.5 mi (12.1 km) 3.5 mi (5.6 km) 2.5 mi (4.0 km) 9600 10.0 mi (16.1 km) 3.5 mi (5.6 km) 2.5 mi (4.0 km)
Page 8
Size — 2.7"H x 2.1"W x 0.7"D (6.9 x 5.3 x 1.8 cm) Weight—0.1 lb. (0.05 kg) NOTE The Sync SHM-NPR MP must be used in pairs. The Sync SHM-NPR MP is compatible with the Mini Driver 4W-S Series (ME750A-ME754A, ME756A).
7 or 53 ms, and carrier status of constantly on or RTS- controlled. Ten models are available: • Sync SHM-NPR MP (DB25) with Surge Protection (4-Screw Terminal Block) (ME729A-MSP) • Sync SHM-NPR MP (DB25) with Surge Protection (4-Screw Terminal Block) (ME729A-FSP)
Page 11
SYNC SHM-NPR MP • Range of up to 11 miles (17.7 km). • Carrier “on” or “controlled” (switch-selected). • Options for easy daisychain installation. • Full- or half-duplex operation. • Transformer (DC) isolated. • Ideal for multipoint configurations. • Built-in high-speed surge protection with power- handling capacity of 600W per wire at 1 ms.
CHAPTER 3: Configuration 3. Configuration The Sync SHM-NPR MP has seven configuration switches, which allow selection of carrier control method, clocking method, RTS/CTS delay, and data rate. This section describes switch locations and explains all possible switch configurations. 3.1 Switch Locations...
SYNC SHM-NPR MP Figure 3-2 shows the orientation of the switches on the SIP, including ON/OFF position. Figure 3-2. Close-up of Configuration Switches. 3.2 Switch Settings All possible settings for the Sync SHM-NPR’s configuration switches are presented in Table 3-1. If you have additional questions about configuration, contact technical support.
Page 14
CHAPTER 3: Configuration 1: N WITCH 2: C WITCH ARRIER NABLE Use switch 2 to specify how the carrier signal is raised. In most point-to-point, full-duplex applications, the carrier signal can remain constantly “high.” In a multipoint environment, contention for the line is controlled by RTS.
Page 15
SYNC SHM-NPR MP 5: RTS/CTS D WITCH ELAY After the host terminal raises a request to send (RTS), the SHM-NPR raises CTS after a slight delay in order to give the remote terminal time to receive an incoming signal. Depending on the type of environment, either a 7- or 53-ms delay can be selected.
4. Installation Once the Sync SHM-NPR is properly configured, it is ready to connect to your system. This section tells you how to properly connect the Sync SHM-NPR MP to the twisted-pair and RS-232 interfaces, and how to operate the unit.
SYNC SHM-NPR MP For your convenience, the Sync SHM-NPR is available with three different twisted-pair interfaces: RJ-11 jack, RJ-45 jack, and terminal blocks with strain relief. 4.1.1 T RJ-11 RJ-45 WISTED ONNECTION SING The RJ-11 and RJ-45 jacks on the SHM-NPR’s twisted- pair interface are pre-wired for a standard telco wiring environment.
Page 18
CHAPTER 4: Installation When you connect two SHM-NPRs, you must use a crossover cable. Figure 4-2 shows how you should construct a crossover cable for an environment where both SHM-NPRs use a 6-wire RJ-11 connector. Use a similar method when you use an RJ-45 connector or a combination of both RJ-11 and RJ-45.
SYNC SHM-NPR MP 4.1.2 T WISTED ONNECTION SING ERMINAL LOCKS If your application requires you to connect two pairs of bare wires to the Sync SHM-NPR, you will need to open the case to access the terminal blocks. The instructions...
Page 20
CHAPTER 4: Installation Figure 4-3. Opening the Sync SHM-NPR. Once the unit has been opened, you will be able to see the terminal blocks located at the rear of the PC board.
Page 21
SYNC SHM-NPR MP 2. Strip the outer insulation from the twisted pairs about one inch from the end. Figure 4-4. Stripping the Outer Insulation from the Twisted Pairs. 3. Strip back the insulation on each of the two twisted-pair wires about 0.25".
Page 22
CHAPTER 4: Installation Ultimately, you will want to construct a two-pair crossover cable that makes a connection with the two Sync SHM-NPRs as shown in Figure 4-6. XMT - - - - - - - - - - - - - - - - - - - - - - - - RCV One pair XMT - - - - - - - - - - - - - - - - - - - - - - - - RCV G - - - - To Shield (Optional) RCV- - - - - - - - - - - - - - - - - - - - - - - - - XMT One pair...
Page 23
SYNC SHM-NPR MP 7. When you finish connecting the wires to the terminal block, the assembly should resemble Figure 4-7. Figure 4-7. Terminal Block with Wires Connected.
Page 24
CHAPTER 4: Installation 8. Place the two halves of the strain-relief assembly on either side of the telephone wire and press together very lightly. Slide the assembly so that it is about two inches (5 cm) from the terminal posts and press together firmly.
Page 25
SYNC SHM-NPR MP 9. Insert the strain-relief assembly with the wire going through it into the slot in the bottom half of the modem case and set it into the recess in the case. Figure 4-9. Inserting the Strain-Relief Assembly into the Modem Case.
Page 26
CHAPTER 4: Installation 10. Bend the top half of the case as necessary to place it over the strain-relief assembly. Do not snap the case together yet. Figure 4-10. Placing the Top Half of the Case Over the Strain- Relief Assembly.
SYNC SHM-NPR MP 4.2 Connection to the RS-232 Interface Once you have connected the twisted-pair wires correctly, simply plug the Sync SHM-NPR directly into the DB25 port of the RS-232 device. After doing so, remember to insert and tighten the two captive connector screws.
4.3 O SHM-NPR MP PERATING THE Once the Sync SHM-NPR MP is properly configured and installed, it should operate transparently—as if it were a standard cable connection. Operating power is derived from the RS-232 data and control signals; there is no “ON/OFF”...
APPENDIX: RS-232 Pin Configurations Appendix: RS-232 Pin Configurations DIRECTION STANDARD “DCE” SETTING DIRECTION 1 - (FG) Frame Ground To Sync SHM-NPR To Mini Driver Transmitter Timing - 15 To Sync SHM-NPR 2 - (TD) Transmit Data To Mini Driver From Sync SHM-NPR 3 - (RD) Receive Data From Mini Driver To Sync SHM-NPR...
