ADC PowerWorx Select Series User Manual page 6

ADCP-80-531 • Issue 4 • July 2004
VENTS
UL/CSA/CE
LABEL
1 TO 8 CIRCUIT BREAKERS
BUS A
(BLANK PANEL IF NO
POWER-ON
CIRCUIT BREAKER)
INDICATOR
(GREEN LED)
BUS B
POWER-ON
INDICATOR
BUS A
(GREEN LED)
CIRCUIT BREAKER
INDICATOR (RED LED)
1 TO 8 CIRCUIT BREAKERS
(BLANK PANEL IF NO
BUS B
CIRCUIT BREAKER)
FRONT VIEW
CIRCUIT BREAKER
INDICATOR (RED LED)
16756-B
PROTECTIVE COVER
PLACED OVER INPUT
MOUNTING
AND OUTPUT POWER,
BRACKETS
GROUND, AND ALARM
FOR 23-IN. (58.42 CM)
CONNECTIONS
RACK MOUNTING
REAR VIEW
Figure 1. Front and Rear View of ADC PowerWorx Select Series Circuit Breaker Panel
with Protective Cover Attached (8/8-Position Panel Shown)
Page 6
© 2006, ADC Telecommunications, Inc.
