ADCP-80-531 • Issue 4 • July 2004

1.18 Weight

The weight of the circuit breaker panel is approximately 10 pounds (4.54 kilograms). The actual
weight is dependent upon the configuration of the panel.

1.19 Color

The color of the circuit breaker panel and mounting brackets is putty white.

1.20 Mounting

The circuit breaker panel can be mounted in a 19- or 23-inch rack (48.26 or 58.42 cm) using the
mounting brackets shown in
inches (25.4, 50.8, 76.2, or 101.6 mm) from the front of the rack. The mounting holes are slotted
to permit installation in racks with WECO 1.00-inch (2.54 cm) hole spacing or EIA 1.25-inch
(3.18 cm) hole spacing.
The following mounting brackets and screws are enclosed with the circuit breaker panel:
• Two brackets for 19-inch rack installations
• Two brackets for 23-inch rack installations
• Eight 5/16-inch (7.936 mm) long, 8-32 chromate finish, thread-forming, flathead screws
for attaching the brackets to the circuit breaker panel
• Four 3/8-inch (9.525 mm) long, 12-24 thread-forming screws and washers for attaching
the brackets to the rack
Caution: Use only the 5/16-inch (7.936 mm) long, chromate finish, flathead, thread forming
screws for attaching the mounting brackets to the circuit breaker panel. Use of any other
hardware could cause contact with internal parts of the panel. If parts are missing, please
contact ADC.
The slotted mounting hole pattern in the mounting brackets compensates for vertical rack
differences and allows mounting the circuit breaker panel in either 1.75- or 2-inch (4.45 or 5.08 cm)
rack spaces.
Page 14
© 2006, ADC Telecommunications, Inc.
Figure 7. The panel can be flush mounted or recessed 1, 2, 3, or 4
