Creative Sound Blaster X-Fi User Manual page 9

Connect the following inputs on powered analog speakers or a home theater receiver to this jack:
2. Line Out 3 jack
3.
Line Out 2 jack
Connect the following inputs on powered analog speakers or a home theater receiver to this jack:
On 4.1 and 5.1 systems: Rear Left and Rear Right
On 7.1 systems: Rear Left, Rear Right and Side Right
4.
Line Out 1 jack
Connect the Front Left and Front Right inputs on powered analog speakers or a home theater receiver to
this jack. You can also connect your stereo headphones with a 3.50 mm (1/8-inch) plug to this jack.
5.
FlexiJack
For SB046X and SB055X series
Performs a 3-in-1 function, supporting Microphone-in, Line-in and Digital I/O connections.
Connect one of the following to this jack:
analog devices like cassette players and other line-level sources
a microphone
the Digital I/O Module*
external digital audio devices that accept stereo PCM or compressed Dolby Digital/DTS Bitstream from
the S/PDIF output
See Configuring your FlexiJack.
For SB073X series
Performs a 3-in-1 function, supporting Microphone-in, Line-in and Optical out connections.
Connect one of the following to this jack:
analog devices like cassette players and other line-level sources
a microphone
external digital audio devices that accept stereo PCM or compressed Dolby Digital/DTS Bitstream from
the Optical output
On a SB073X series card, this jack does not have the Digital-in function to support the Digital I/O Module.
6.
Creative Proprietary connector
Provides a proprietary connection for Creative devices. Do not use this connector unless instructed to do so.
7.
Aux In connector
Connect an analog CD cable (available separately) from the analog output on an audio device like a TV
tuner to this connector.
8.
Power connector
Powers the X-Fi I/O Console* via the AD_Link connector. Connect a power cable from your computer's
power supply to this connector.
9.
AD_EXT connector
Connect one end of the AD_EXT cable to this connector. Connect the other end to the AD_EXT connector
on the X-Fi I/O Drive*.
10.
Front Panel Header Audio connector
Connect one end of the Intel ®
Panel Header (for SB073X series) for specifications.
On 5.1 systems: Front Center and Subwoofer
On 7.1 systems: Front Center, Subwoofer and Side Left
Front Panel Audio cable (available separately) to this connector. See Front
