- Page 1 SIENNA VISION VIDEO ENTERTAINMENT SYSTEM DIAGNOSTIC MANUAL MDC #0017–00314–SVC Rev: B 12/17/01...
-
Page 2: Table Of Contents
TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Table of Contents Toyota Sienna Video Entertainment System (VES) Diagnostic Manual Initial Test Sienna VES Component and Connector Locations Sienna VES Component and Harness Map Troubleshooting Table Diagnostic Error Codes Check 1 –... -
Page 3: Initial Test
TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Initial Test Inspection Initial Test Note: Use this test to confirm the customer complaint/failure condition, such as picture no sound, won’t eject, no power to VCP, etc.. Then review the Troubleshooting Table beginning on page 5 for repair procedures. -
Page 4: Sienna Ves Component And Connector Locations
TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Sienna VES Component and Connector Locations Page 3 of 20 pages... -
Page 5: Sienna Ves Component And Harness Map
TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Sienna VES Component and Harness Map Page 4 of 20 pages... -
Page 6: Troubleshooting Table
TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Troubleshooting Table Determine the failure condition, and then repair it by using the TROUBLESHOOTING TABLE. The VES can communicate certain protection modes (which can resemble system failure) by flashing the Status LED’s in the monitor assembly. These modes are defined on the next page. -
Page 7: Diagnostic Error Codes
TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Diagnostic Error Codes The Status LED flashes in groups of one, two, or three flashes to communicate what error con- ditions are present. These error conditions are: One flash – “Dew” or moisture present in the video cassette player. - Page 8 TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Check 1: Fuse Check Turn OFF Ignition Check RADIO FUSE #2 in instrument panel Go to next step. fuse box. (Continuity/voltage test). FM Modulator Noise Filter Cable Check RADIO FUSE #2 in instrument panel fuse box.
-
Page 9: Check 2: Ves Harness Connection Check
TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Check 2: VES Harness Connection Check Page 8 of 20 pages... -
Page 10: Check 3: Ves Harness Ground Check
TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Check 3: VES Harness Ground Check Page 9 of 20 pages... -
Page 11: Check 4: Vcp Ves Harness Check
TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Check 4: VCP VES Harness Check Page 10 of 20 pages... -
Page 12: Check 5 – Monitor Assembly/Ground Distribution Check
TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Check 5: Monitor Assembly/Ground Distribution Check Page 11 of 20 pages... - Page 13 TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Check 6: FM Modulator/FM Frequency Check Page 12 of 20 pages...
- Page 14 TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Check 7: Volume Settings Check Page 13 of 20 pages...
-
Page 15: Check 8: Fm Modulator Harness Check
TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Check 8: FM Modulator Harness Check Page 14 of 20 pages... -
Page 16: Check 9: Aux Board/Monitor Assembly Check
TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Check 9: AUX Board/Monitor Assembly Check Page 15 of 20 pages... -
Page 17: Check 10: Switched Voltage Check
TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual Check 10: Switched Voltage Check Page 16 of 20 pages... -
Page 18: Sienna Ves Component Removal Guide
TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual SIENNA VES COMPONENT REMOVAL GUIDE MONITOR ASSEMBLY REMOVAL – With Sunroof REMOVE DOME LIGHT Remove both lens covers Remove the two (2) Phillips dome light mounting screws REMOVE OVERHEAD CONSOLE SCREWS... - Page 19 TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual WIREHARNESS DISCONNECTION Disconnect all three (3) harnesses from the mon- itor assembly This may require two persons, one to hold the assembly and one to unplug the connections The assembly is now free to remove MONITOR ASSEMBLY REMOVAL –...
- Page 20 TOYOTA SIENNA 2001 – VIDEO ENTERTAINMENT SYSTEM Service Diagnostic Manual REMOVE FM MODULATOR FM Modulator Locate FM Modulator Remove wire ties holding FM Modulator Disconnect wire harness from FM Modulator CENTER FLOOR CONSOLE REMOVAL REMOVE SIDE SCREWS Remove left and right side Phillips screws from...
