Page 1: Troubleshooting
Technical manual CT / CTM / CTS / CTMS / CBT / CBTM / CTMC / TS SECTION 6 TROUBLESHOOTING FOX2 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... - Page 2 Technical manual Document: Troubleshooting SECTION 6 Modification journal: Revision: Data: Modification Initials: 2011-01-04 Basic document 2013-03-05 Various changes Overview modifications REVISION REVISION REVISION Changes in content, corrections New paging REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten...
-
Page 3: Table Of Contents
5 ISO view Chassis ..................................48 6 Quick test ....................................49 8 Steam module ..............................50 8.1 Error messages ..................................50 8.2 ISO view ....................................51 8.3 Front view ....................................52 8.4 Back view ....................................53 8.5 Quick test steam module ................................54 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 4: Overview Display Messages
TX0122 Steamboiler not ready Steam (Kap. 8.1) TX0123 Low water level in steamboiler Steam (Kap. 8.1) TX0124 Hot water rinse Steam (Kap. 8.1) Press rinse key TX0125 Waterflow error Hydraulics (Kap. 6.1) REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... - Page 5 Error grinder left-hand side Mechanics (Kap. 5.1) TX0164 Cleaning interrupted Chassis (Kap. 4.1) Please press rinse key TX0167 Cleaning interrupted Chassis (Kap. 4.1) Remove grounds drawer TX0174 Remove and empty grounds drawer Chassis (Kap. 4.1) REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten...
- Page 6 Affects module TX0188 Check milk temperature Chassis (Kap. 4.1) TX0201 Cold start rinse Chassis (Kap. 4.1) / Hydraulics (Kap. 6.1) Please press rinse key TX0241 Machine rinsing Chassis (Kap. 4.1) ATTENTION HOT! REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten...
-
Page 7: Service Menu „System Check
2. The „Enter PIN“ window appears. Enter code and confirm with Enter PIN ****** 3. Following screen appears: The service menu can always be left by pressing the top left corner of the display. REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 8: Inputs
Shows the current level of the coffee brewer‘s tank. Pot level step Remove cleaning key to check the contact. Milkcleaningkey Remove cleaning key and press the contact pin inside the cleaning key‘s housing to Milkcleaningtablet check the contact. REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 9: Outputs
Tank valve on valve block opens (you should hear a „click“ noise) Potvalve Coffee outlet valve on valve block opens (you should hear a „click“ noise) Coffeeoutletvalve Tank drain valve on valve block opens (you should hear a „click“ noise) Tankdrainvalve REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 10: Touchpanel Test
A grid will appear on the screen. After every touch on the screen a red „dot“ should appear on the same spot. Zum Verlassen Touch 2s berühren to leave, press and hold for 2s To leave the test screen, press for 2 seconds on any place on the touchscreen. REV-1 6.10 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 11: Touchscreen Fox
• Recommendation of CF card for FOX 70-Print version A-C: CF card type „take MS“ • From FOX 70-Print version D the CF card type does not matter anymore • If this action does not solve the problem, proceed with step 4 6.11 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 12: Overview Fox-Print
• If this action does not solve the problem, proceed with step 7 Step 7 • Switch off machine • Change the CPU • Reconnect all cables and switch machine back on REV-1 6.12 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 13: Overview Cpu
FOX-Print index Overview CPU The CPU is located on the back of the chassis (see particular chassis ISO views). Connection-LED FOX-Print (blinking = connection OK) Connection- cable CPU - FOX-Print slot 6.13 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 14: Chassis
- micro switch - The mobile piston is blocked and - fix piston the brew cylinder cannot travel back to the micro switch - The brew cylinder cannot travel over the fix piston. REV-1 6.14 © 2011 by Thermoplan AG, Änderungen vorbehalten... - Page 15 POD product TX0150 Remove cleaning tablets Cleaning tablets are in cleaning key Remove cleaning tablets from clea- when cleaning not in progress ning key. They must only be inserted during cleaning. 6.15 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten...
- Page 16 Cold start rinse Rinse for start- and warm-up of Press rinse key Please press rinse key machine TX0241 Machine rinsing Warning note during rinse Wait until rinse has finished ATTENTION HOT! REV-1 6.16 © 2011 by Thermoplan AG, Änderungen vorbehalten...
-
Page 17: Ctm Front View
SECTION 6 CTM Front view Connection mechanical module Mechanical clip Main switches Hydraulic clip Cleaning key Connections hydraulic module Hydraulic clip Mechanical clip Cleaning Check valve Cleaning (not used) Brew Brew 6.17 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 18: Ctm Back View
Technical manual Chassis SECTION 6 CTM Back view Connectioin mechanical module Net clips Connections hydraulic module REV-1 6.18 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 19: Ctm Bottom View
Technical manual Chassis SECTION 6 CTM Bottom view Drain Main water connection Flooding area Flooding sensors 6.19 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 20: Ctm Iso View
Technical manual Chassis SECTION 6 CTM ISO view Main switch Cleaning key REV-1 6.20 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 21: Ctm Iso View 2
Technical manual Chassis SECTION 6 CTM ISO view 2 Milk valve Drain gate valve Power print (Powerboard) Cleaning key 6.21 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 22: 4.7 Cbtm Front View
4.7 CBTM Front view Connection mechanical module Mechanical clip Hydraulic clip Main switch Connection Brew module Cleaning Connection Hydraulic module Hydraulic clip Hydraulic clip Cleaning Check valve Cleaning (not used) Brew Brew REV-1 6.22 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 23: Cbtm Back View
Technical manual Chassis SECTION 6 CBTM Back view Connection mechanical module Connection brew module Net clips Connection hydraulic module 6.23 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 24: Cbtm Bottom View
Technical manual Chassis SECTION 6 CBTM Bottom view Check valve Main water connection Flooding area Flooding sensors REV-1 6.24 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 25: Cbtm Iso View
Technical manual Chassis SECTION 6 4.10 CBTM ISO view Main switches Cleaning key 6.25 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 26: Cbtm Iso View 2
Technical manual Chassis SECTION 6 4.11 CBTM ISO view 2 Milk valve Drain gate valve Powerprint (Powerboard) Cleaning key REV-1 6.26 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 27: Mechanical Module
TX0139 Bean hopper missing or command Bean hopper is not mounted or the 1. Place bean hopper correctly unit open command desk is open 2. Close command desk 3. Check contacts 6.27 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... - Page 28 2. Perform rinse 3. Check mechanical module TX0163 Error grinder left-hand side Grinder error left-hand side 1. Empty grounds drawer + vacuum-clean grinders 2. Perform rinse 3. Check mechanical module REV-1 6.28 © 2011 by Thermoplan AG, Änderungen vorbehalten...
-
Page 29: Water Circulation
Hot water from coffee boiler (through cleaning key) Connector for mec. module Teflon pipe to brew chamber Brew chamber over mobile piston Through fix piston Coffee outlet Every second cycle also runs through the brew valve! 6.29 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 30: Iso View
Technical manual Mechanical module SECTION 6 ISO view Grinder motor Gear belt Brew chamber Brew chamber drive Grinder left Coffee outlet valve Connection Brew chamber motor Coffee outlet Grinder right REV-1 6.30 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 31: Top View
Gear belt Brew chamber drive Connection Connection mechanical module cleaning Gear Grinder motor Brew chamber motor Brew chamber Grinder left Grinder right Coarsness setting Coarsness setting fine coarse fine coarse Spindle 6.31 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 32: Back View
Technical manual Mechanical module SECTION 6 Back view Grinder motor Gear belt Brew chamber drive Connection Connection Gear Gear belt mechanical module cleaning Grinder drive REV-1 6.32 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 33: Bottom View
Technical manual Mechanical module SECTION 6 Bottom view Connection cleaning Connection mechanical module Gear belt Grinder drive 6.33 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 34: Iso View Brewing Unit
Technical manual Mechanical module SECTION 6 ISO view Brewing unit Backmost bearing block Spindle Brew chamber Front bearing block Brew chamber motor Fix piston REV-1 6.34 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 35: Quick Test
GND micro switch, brew motor 5 Signal brew motor 19 not set 24VDC+ (reed, valve) 6 Micro switch 5VDC 13 Coffee outlet valve 20 Grounding 7 not set 14 not set 21 Heater N 6.35 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 36: Hydraulic Module
Milk pump not recognised TX0161 Please wait Machine rinses Wait until rinse is finished TX0201 Cold start rinse Rinse for start- and warm-up of Press rinse key Please press rinse key machine REV-1 6.36 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 37: Top View
Tea valve Heater cutout (after over- heating press middle button in again) Flowmeter Overpressure Hot water boiler Heater cutout / Drain (after overheating press middle button in again) 6.37 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 38: Back View
Hydraulic module SECTION 6 Back view NTC coffee boiler Air valve Tea valve Tea connection Cleaning connection Brew connection Pump unit Brew valve Hot water boiler Overpressure valve Flowmeter Connections Hydraulic module REV-1 6.38 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 39: Milk Way Pump Unit
Technical manual Hydraulic module SECTION 6 Milk way pump unit Milk way / Cleaning way Rinse way 6.39 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 40: Water Way Pump Unit
Technical manual Hydraulic module SECTION 6 Water way pump unit Water way Cleaning way REV-1 6.40 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 41: Iso View Pump Unit
Rinse valve: Needed to rinse the milk system after every milk product dispensing. Clean valve: Needed to clean the complete system. Air valve: Needed to add air to the milk for producing milk froth. 6.41 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 42: Iso View Valve Block
Technical manual Hydraulic module SECTION 6 ISO view Valve block Tea valve Cleaning valve Cleaning connection connection Brew connection Brew valve REV-1 6.42 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 43: Quick Test
C Grounding Motor water pump coil C 4 not set Motor milk pump coil A 5 not set Motor milk pump coil B 6 not set Motor milk pump coil C 6.43 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 44: Brew Module
- Short circuit on tub sensors in - Check tub sensors and replace if chassis. necessary - Short circuit on cable between tub - Check cable and replace if sensors and CPU. necessary REV-1 6.44 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 45: Iso View
Technical manual Brew module SECTION 6 ISO view Sensor unit Brew Tank 6.45 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 46: Back View
Technical manual Brew module SECTION 6 Ruckansicht Brew tank Connection brew tank REV-1 6.46 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 47: Iso View Sensor
Technical manual Brew module SECTION 6 ISO view Sensor 6.47 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 48: Iso View Chassis
Technical manual Brew module SECTION 6 ISO view Chassis Pump Jug valve Tank drain valve REV-1 6.48 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 49: Quick Test
5 not set 12 not set 24VDC+ (Motor coffee p. , print, valve) 6 not set 20 not set Motor coffee pump 24VDC- 7 Print pressure sensor 14 not set 21 Grounding 6.49 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 50: Steam Module
These error messages of the steam module are only shown on the model BW3-CTS. The BW3-CTMS does not show these messages, because in the BW3-CTMS a complete TS module is built-in! REV-1 6.50 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 51: Iso View
Technical manual Steam module SECTION 6 ISO view Pressure relief valve Security probe Steam valve Level sensor Water inlet Purge mix valve Tea valve Fill valve 6.51 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 52: Front View
Pressure switch Drain drop Reset buttons thermal breakers Notice If there is a temperature on the steam boiler of greater than 165°C (329°F), the thermal breaker will interrupt the electrical current. REV-1 6.52 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 53: Back View
Technical manual Steam module SECTION 6 Back view Heater 1 Heater 2 6.53 REV-1 © 2011 by Thermoplan AG, Änderungen vorbehalten... -
Page 54: Quick Test Steam Module
18 not set 25 A2 Triac Steam 2 5 not set 12 Mixing / tea valve 19 not set 6 not set 13 Steam valve 7 not set 14 Filling valve REV-1 6.54 © 2011 by Thermoplan AG, Änderungen vorbehalten...
