• MAIN-A/MAIN-B UNIT
(TOP VIEW)
TONE FILTER
(Q39)
AF AMP
(IC21)
IF DEMODULATOR IC
(IC1)
1ST IF AMP
(Q4)
1ST IF FILTER
(Q4)
PLL IC
(IC4)
VCO SW
(Q15)
RIPPLE FILTER
(Q17)
CPU5V LINE REGULATOR
(IC10)
2 - 2
2ND IF FILTER
BANDWIDTH SWITCH
(Q40)
APC AMP
(IC2)
R8 LINE REGULATOR
(Q26)
VCC LINE SW
(Q23)
+8V LINE REGULATOR
(IC9)
