Icom IC-F6012 Service Manual page 32

SECTION 8.
[CHASSIS PARTS]
REF ORDER
NO. NO.
J1 6510004880 MR-DS-E 01 <SSC>
W1 8900011800 OPC-1199
MP1 8010019065 2601 CHASSIS-5
8010019065 2601 CHASSIS-5
8010019135 2601 LONG CHASSIS-5
8010019135 2601 LONG CHASSIS-5
8010019135 2601 LONG CHASSIS-5
8010019135 2601 LONG CHASSIS-5
MP2 8110007821 2601 COVER-1 RO
MP3 8810008661 PHBT M3 X 8 NI-ZC3
MP4 8810008661 PHBT M3 X 8 NI-ZC3
MP5 8810008661 PHBT M3 X 8 NI-ZC3
MP6 8810008661 PHBT M3 X 8 NI-ZC3
MP7 8810009991 PHBT M3 X 8 NI-ZK3
MP8 8810009991 PHBT M3 X 8 NI-ZK3
[MAIN–A UNIT] (For low band versions)
REF ORDER
NO. NO.
J1* 6510026770 AXK540147YG
J2* 6510027960 04-6294-040-000-800
J4 6450000140 HSJ0807-01-010
J6* 6510022891 B13B-ZR-SM4-TF (LF) (SN)
J7* 6510014961 B2B-ZR-SM4-TF (LF) (SN)
S1* 2260003180 MINISMDC050F-2 CN
W1* 7030012290 RDS2T0R0
W2 8900011863 OPC-1195C
EP4* 6910010280 HF70BB9.5X10.4X4.9
EP5* 6910010280 HF70BB9.5X10.4X4.9
MP1* 8510019340 3179 VCO CASE Y1142
MP2 8510019350 3179 VCO COVER Y1143
MP3 8510015110 2602 M-PLATE Y660
MP5* 8510019570 3179 MAIN SHIELD Y1159
MP10* 8930072530 SPONGE (JN)
[MAIN–B UNIT] (For high band versions)
REF ORDER
NO. NO.
J1* 6510026770 AXK540147YG
J2* 6510027960 04-6294-040-000-800
J4 6450000140 HSJ0807-01-010
J6* 6510022891 B13B-ZR-SM4-TF (LF) (SN)
J7* 6510014961 B2B-ZR-SM4-TF (LF) (SN)
S1* 2260003180 MINISMDC050F-2 CN
W1* 7030012290 RDS2T0R0
W2 8900011863 OPC-1195C
EP4* 6910010280 HF70BB9.5X10.4X4.9
EP5* 6910010280 HF70BB9.5X10.4X4.9
MP1* 8510019340 3179 VCO CASE Y1142
MP2 8510019350 3179 VCO COVER Y1143
MP3 8510015110 2602 M-PLATE Y660
MP5* 8510019570 3179 MAIN SHIELD Y1159
MP10* 8930072530 SPONGE (JN)
*: Refer to "BOARD LAYOUTS" for the location.
Screw abbreviations
MECHANICAL PARTS
DESCRIPTION
[EUR-01]
[EXP-01]
[USA-01]
[USA-02]
[EXP-03]
[EXP-04]
DESCRIPTION
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[FRONT UNIT]
REF ORDER
QTY.
NO. NO.
J1 6450002210 3017-8821 <KIN>
1
J2* 6510027960 04-6294-040-000-800
J3* 6510022022 14FLT-SM2-TB (LF) (SN) (M)
1
SP1 2510001221 C052SB500-14 <OSC>
1
1
W1 8900010503 OPC-1046B-1 (P0.5N40L55)
1
1
MP1 8210026500 3334 FRONT PANEL
1
MP2 8930081280 3334 FRONT KEY <SEP>
1
MP3 8310076970 3334 FRONT PLATE
1
MP4 8210026510 3334 REFLECTOR
8
MP5 8610014010 KNOB N-386
2
MP7 8810009131 PHBT M3 X12 NI-ZC3
2
MP9 8930059000 2601 SP NET
1
MP11 8930070850 2979 VOL RUBBER (TOT)
4
MP12* 8510015150 2602 F-SHIELD
2
MP13* 8930058840 SHIELD SPONGE (T)
[ACCESSORIES]
QTY.
REF ORDER
NO. NO.
1
MC1 (Optinal) HM-152
1
1
W1 8900011781 OPC-1194A
1
8900011781 OPC-1194A
1
(Optinal) OPC-1132A
(Optinal) OPC-1132A
1
(Optinal) OPC-1132A
(Optinal) OPC-1132A
1
W2 8900000731 OPC-049A
1
MP1 8010019151 2601 MOBIL BRACKET-1
1
MP3 8820000530 FLANGE BOLT M4 X 8 NI
1
MP4 8810000471 PH M5 X12 (+/-) ZC3
MP5 8810005841 PHA M5 X20 ZC3
1
MP6 8850000150 FLAT WASHER M 5 NI BS
1
MP7 8850000391 S-WASHER M5 ZC3
1
MP8 8830000121 NUT M 5 ZC3
1
MP9 8950005110 2289 MIC HANGER Y468
1
MP10 8310073440 3179 LCD LABEL M6K
MP11 8810004700 PHA M3 X16 SUS
MC1
QTY.
1
1
1
1
1
1
W1
1
1
1
1
1
1
1
1
1
MP6
MP7
8 - 1
DESCRIPTION
DESCRIPTION
W2
MP9
MP11
MP1
MP10
MP4 (M5×12)
MP8
MP3 MP5 (M5×20)
QTY.
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
QTY.
1
[EUR-01] 1
[EXP-01] 1
[USA-01] 1
[USA-02] 1
[EXP-03] 1
[EXP-04] 1
1
1
4
4
4
4
4
4
1
1
2
