Backyard Creations ARV06300 Assembly Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Installer: Leave these instructions with consumer.
Consumer: Keep these instructions for future reference
DANGER

If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide which has no odor.
Using it in an enclosed space can kill
you.
Never use this appliance in an enclosed
space such as a camper, tent, car or
home.
Questions, Problems, Missing Parts? Before returning to
your retailer, call our customer service department in the
US and Canada at 1-800-416-3511, Monday-Friday, 9 a.m.–
5 p.m. Eastern Time.
Sep-31-2014

ASSEMBLY INSTRUCTIONS

CSA Model 98300
SKU:272-4302
TACOMA FIREPIT
.
WARNING:
Improper installation, adjustment alteration,
service or maintenance can cause injury or
property damage. Read the installation,
operating and maintenance instructions
thoroughly before installing or servicing this
equipment.
WARNING: For Outdoor Use Only
FOR
USE
WITH
CYLINDER WITH TYPE 1 CONNECTION OR FOR
USE WITH NATURAL GAS AFTER CONVERSION
KIT IS INSTALLED (MUST BE PROFESSIONALLY
INSTALLED).
WARNING:
USE FACTORY APPROVED
REPLACEMENT PARTS AND
ACCESSORIES ONLY. USE
OF UNAPPROVED PART OR
ACCESSORIES CAN VOID
THE WARRANTY ON THIS
PRODUCT AND RESULT IN
AHAZARDOUS CONDITION.
PLEASE CONTACT US FOR
INFORMATION REGARDING
REPLACEMNT HOSES,
THERMOCOUPLES,ELECTR
ODES,IGNITION
MODULES,LAVAROCKS,LO
GS, FIRE ICE, ETC.
1
ARV06300
20LB
(9KG)
PROPANE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARV06300 and is the answer not in the manual?

Questions and answers

Related Manuals for Backyard Creations ARV06300

Summary of Contents for Backyard Creations ARV06300

  • Page 1: Assembly Instructions

    ASSEMBLY INSTRUCTIONS CSA Model 98300 SKU:272-4302 ARV06300 TACOMA FIREPIT Installer: Leave these instructions with consumer. Consumer: Keep these instructions for future reference DANGER   WARNING:  If you smell gas: Improper installation, adjustment alteration, 1. Shut off gas to the appliance.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Safety Information Important About Propane Specification Parts Identification List Installation 7-11 Natural Gas Conversion Lighting Instructions Batteries Maintenance Troubleshooting Guide Warranty...

  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54; International Fuel Gas Code. ; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, B149.2, as applicable. The appliance and its appliance main gas valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5kPa).

  • Page 4: Important About Propane

    IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS A self contained LP-gas cylinder for use with this appliance must have a capacity of 20 lbs. and must be equipped with a Type 1 connector and an OPD (overfill protection device). See Figure 1. The LP-gas supply cylinder to be used must be constructed and marked in accordance with the specification for LP-gas cylinders of the U.S.

  • Page 5: Parts Identification List

    PARTS IDENTIFICATION LIST PART DESCRIPTION PART# CONTROL KNOB FP0245 GAS VALVE FP0307 THERMOCOUPLE FP0004 LP REGULATOR HOSE FP1329 ELECTRODE FP1330 GAS TUBE FP1689 ORIFICE ELBOW FP1385 IGNITION MODULE FP1666 ORIFICE BRACKET FP1667 PROPANE ORIFICE FP1299 NATURAL GAS ORIFICE FP1300 “AAA” BATTERY(1.5V) HW0705 FOOTCAP FC0660...
  • Page 6 MIDDLE PANEL FP1673 BOTTOM PANEL FP1674 BACK PANEL FP1675 DOOR PANEL FP1676 BURNER COVER FP1677 BURNER COVER FP1678 PROTECTIVE RING FIREPAN/BURNER FP1679 ASSEMBLY SUPPORT BAR-1 FP1680 SUPPORT BAR-2 FP1681...

  • Page 7: Installation

    INSTALLATION 1. Identify parts packed in carton against the parts list. Remove all protective materials and set parts on a flat, non-abrasive surface. IMPORTANT NOTE: WE RECOMMEND TWO PEOPLE WORK TOGETHER TO ASSEMBLE THE PRODUCT. 2. Place the back panel upside down on a flat, non-abrasive surface. Open it as shown in Figure 2.
  • Page 8 4. Attach the bottom panel to legs by using four 1/4"x30 mm bolts and washers as shown in Figure 4.Guide the bolts through holes in the bottom panel, into pre-drilled holes in the legs. Hand tighten only. Figure 4 5. Carefully place the middle panel inside back panel with bottom panel as shown in Figure 5.
  • Page 9 6. Attach the bottom panel to the back panel by using two 1/4"x30 mm bolts and washers as shown in Figure 6. Guide the bolts through holes in the bottom panel, into pre-drilled holes in the back panel. Hand tighten only. Figure 6 7.
  • Page 10 9. After making any necessary adjustments to the alignment of the all parts, use the hex bolt driver to tighten all bolts. Do not over tighten. Over tightening may strip bolts. 10. With the help of another person, Attach the table top to the complete base by using four 1/4"x18 mm bolts and washers as shown in Figure 9.
  • Page 11 12. Tighten threaded knobs (L) found on tank tray (Figure.11) ) so that the LP tank cannot move from side to side. Do not remove plastic cap from end of threaded section. Figure 9 13. Pour the lava rocks(not include) into the burner pan completely covering the burner.

  • Page 12: Natural Gas Conversion

    NATURAL GAS CONVERSION Natural gas conversion must be performed only by your natural gas provider or service company. Step 1- At the control panel, disconnect the rubber gas hose from the gas valve. Step 2- Below the burner, disconnect the aluminum gas tube from the orifice elbow. Step 3- Remove the 2 M4 nuts from the orifice holder and remove the orifice bracket assembly.

  • Page 13: Lighting Instructions

    Step 5- Stick the conversion label on the rating plate as shown in Figure 15. Metal Rating Plate Serial Number _________________ Model Number: 98300 CAUTION: The gas pressure regulator provided with this appliance must be used. This regulator is set for an outlet pressure of This appliance has been converted to use Natural Gas.

  • Page 14: Batteries

    control knob in for 10 to 15 seconds. Release the control knob. The control knob should pop back out and then remain lit. Note: If the fire does not light, turn the knob to the “OFF” position and wait five (5) minutes before trying again.

  • Page 15: Troubleshooting Guide

    Figure 18 TROUBLESHOOTING GUIDE PROBLEM CAUSE REMEDY Check that gas tank valve is open. Turn control knob to “ON” and push control No Propane Gas at Burner knob in. Make sure tank has propane gas. Check that AAA battery is installed with Burner won’t light negative (-) end first and has a charge.

  • Page 16: Warranty

    ONE-YEAR LIMITED WARRANTY What is Covered Under This Warranty? The item you have purchased is warranted against defects in material and workmanship for the following parts from the date of purchase for the period of warranty as outlined below, but only when the unit is installed and operated in accordance with the instructions in this Owner’s Manual and in compliance with local building and fire codes: Limited 1 Year •...
  • Page 17 that limitation may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state.
