- Page 1 Installation GUIDE 6 SERIES Built-in Electric Single and Double Wall Ovens MVSOE630 / CMVSOE630 MVDOE630 / CMVDOE630...
-
Page 2: Table Of Contents
Table of Contents Warnings & Important Safety Information ________________________________________________________________ 2 Dimensions _________________________________________________________________________________________ 4 Specifi cations _______________________________________________________________________________________ 5 Cutout Dimensions___________________________________________________________________________________ 6 Standard ____________________________________________________________________________________ 6 Integrated ___________________________________________________________________________________ 7 Flush _______________________________________________________________________________________ 8 Electrical Requirements _______________________________________________________________________________ 9 General Information __________________________________________________________________________________ 9 Installation ________________________________________________________________________________________ 10 Final Preparation ___________________________________________________________________________________ 13 Performance Checklist _______________________________________________________________________________ 13 Service &... -
Page 3: Safety Warnings
Safety Warnings DANGER Hazards or unsafe practices which WILL result in severe personal injury or death WARNING Hazards or unsafe practices which COULD result in death or severe personal injury CAUTION Hazards or unsafe practices which COULD result in minor personal injury. -
Page 4: Dimensions
Dimensions 30” Single Oven 29-3/8” (74.6 cm) 30” Double Oven 51-3/8” (130.5 cm) -
Page 5: Specifi Cations
Specifi cations Description MVSOE630 MVDOE630 Overall width 29-3/4” (75.6 cm) Overall height 29-3/8” (74.6 cm) 51-3/8” (130.5 cm) Overall depth To front of door glass 24” (61.0 cm) To front of handle 26-7/16” (67.2 cm) Cutout width Standard Install 28-1/2” (72.4 cm) Flush mount 30”... -
Page 6: Cutout Dimensions
Cutout Dimensions - Standard 30” Double Oven 30” Single Oven 2 ” - 1 / - 1 / ( 6 1 ” ( 7 1 4 ” ( 7 2 5 ” ( 1 2 2 ” - 1 / ( 6 1 ”... -
Page 7: Integrated
Cutout Dimensions - Integrated 30” Double Oven 30” Single Oven Finished Finished Surfaces Surfaces 51-1/2” (130.8 cm) 29-1/2” 3/4” 5 ” 3/4” (74.9 cm) ( 1 2 (1.9 cm) (1.9 cm) Vertical Vertical 5 ” Blocking Junction ( 1 2 Blocking on both on both... -
Page 8: Flush
Cutout Dimensions - Flush Mount 30” Double Oven 30” Single Oven Finished Finished Surfaces Surfaces 51-1/2” (130.8 cm) 29-1/2” 3/4” 5 ” 3/4” (74.9 cm) (1.9 cm) ( 1 2 (1.9 cm) Vertical Vertical Blocking 5 ” Junction ( 1 2 Blocking on both sides... -
Page 9: Electrical Requirements
Electrical Requirements WARNING FIRE OR ELECTRICAL SHOCK HAZARD DO NOT use an extension cord with this appliance. Such use may result in fi re, electrical shock or other personal injury. • Oven requires a separate, grounded 4-wire, 240V (AC), 30 amp (single ovens) and 50 amp (double ovens) service with its own circuit breaker. -
Page 10: Installation
General Information Site Preparation Note: It is recommended that a thorough site inspection be conducted PRIOR to unpacking and moving this appliance. • Confi rm available access to adequate power—see electrical requirements. ° Single oven units require a 30 amp circuit °... - Page 11 Installation Remove racks. Unscrew pallet screws from side of oven. *Note: Check local code to see which wiring option should be used when grounding the unit. Green White White Neutral Neutral Green Black Black Wiring option 1* Wiring option 2* (connect the white and green to the incoming (connect the white to the incoming neutral, neutral)
- Page 12 Installation Push oven straight in. Attach screws to the side of the framing. Note: Two screws for single ovens, four screws for double ovens (screws not included). Replace racks Replace door Close door Open door completely. Rotate door hinge to locked position.
-
Page 13: Final Preparation
Final Preparation 1. Some stainless steel parts may have a protective wrap, which must be peeled off . All stainless steel body parts should be wiped regularly with hot, soapy water at the end of each cooling period and with liquid cleaner designed for this material when soapy water will not do the job. -
Page 14: Service & Registration
Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at 1-888-(845-4641), or write to: VIKING RANGE, LLC... - Page 15 Record the information indicated below. You will need it if service is ever required. Model number ________________________________________________________________________ Serial number _________________________________________________________________________ Software Version ______________________________________________________________________ Date of purchase ______________________________________________________________________ Date installed _________________________________________________________________________ Dealer’s name ________________________________________________________________________ Dealer's Address ______________________________________________________________________ If service requires installation of parts, use only authorized parts to ensure protection under the warranty. KEEP THIS MANUAL FOR FUTURE REFERENCE.
- Page 16 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-(845-4641) or visit our web site at vikingrange.com in the US or brigade.ca in Canada 060119-000A EN (053017)
