- Page 1 AC Power For Business-Critical Continuity™ Liebert GXT3-10000T220 ® ™ User Manual, 10kVA, 50/60 Hz, 120/208/220V More user manuals on ManualsBase.com...
- Page 2 More user manuals on ManualsBase.com...
-
Page 3: Table Of Contents
TABLE OF CONTENTS ..........1 MPORTANT AFETY NSTRUCTIONS... - Page 4 Figure 8 Liebert GXT3-10000T220 with External Battery Cabinet ....... 11 Figure 9 System block diagram.
-
Page 5: Important Safety Instructions
MPORTANT AFETY NSTRUCTIONS SAVE THESE INSTRUCTIONS This manual contains important safety instructions. Read all safety and operating instructions before operating the uninterruptible power system (UPS). Adhere to all warnings on the unit and in this manual. Follow all operating and user instructions. This equipment must be operated only by individuals who are properly trained and qualified. - Page 6 To ensure safety, observe the following precautions: • Turn Off and isolate the Liebert GXT3 before cleaning it. Use only a soft cloth; never use liquid or aerosol cleaners. • Never block or insert any objects into the ventilation holes or other openings of the UPS.
- Page 7 Operating this device in a residential area is likely to cause harmful interference that users must correct at their own expense. The Liebert GXT3 series complies with the requirements of EMC Directive 2004/108/EC and the published technical standards. Continued compliance requires installation in accordance with these instructions and use of accessories approved by Emerson.
-
Page 8: Introduction And System Description
The liquid crystal display is used for controlling operation of the UPS, as well as monitoring its status, condition, alarm status and history. For ease of use, the Liebert GXT3-10000T220 features a light-emitting diode (LED) display to indicate operational status. It also provides self-diagnostic tests, a combination On/Alarm Silence/Battery Test button, a Standby button, user configurable program and two levels of alarms when the unit is operating on battery. -
Page 9: Device Overview
Overview of UPS devices and batteries Type Model # Nominal power ™ UPS with Integrated Battery Liebert GXT3-10000T220 10000VA/90000W ® ™ Battery Cabinet Liebert GXT3-240TBATTCE — ® ™ Figure 2 Liebert GXT3-10000T220 front and rear views Control Panel Liquid Crystal Display Push Button... -
Page 10: Unpacking The Ups And Site Preparation
The UPS is heavy and will roll when on an incline. When removing the unit from its shipping pallet, use at least two persons. 1. Using a pallet jack, move the Liebert GXT3-10000T220 near its installation site. 2. Unlock all the snaps securing the shipping case to the shipping pallet. -
Page 11: Environmental Conditions
UPS operation in sustained temperatures outside the range of 15-25°C (59°-77°F) will reduce battery life. Access to Area The area where the Liebert GXT3-10000T220 is to be placed must have sufficient space for installation procedures and for routine maintenance. The UPS is narrow enough to pass through standard doorways. -
Page 12: Installation
If the Maintenance Bypass Breaker is in the Bypass position, output power is available immediately upon application of AC input. Suggested Cable Sizes Table 2 Connection data * ™ ® Description Units Liebert GXT3-10000T220 Connector size AWG (mm 6 (10) Max input current Arms ∅ Input cable size (... -
Page 13: External Electrical Connections
Once installation has been completed, adjust leveling feet to prevent the UPS from moving. Connecting Utility and Load ® Connect the utility supply to the input terminals of the UPS. If the Liebert GXT3-10000T220 ™ supplied by single-phase utility, connect the live phase to input L1. -
Page 14: Input And Output Connection Requirements
Installation Figure 6 Dual source input supply—input and output connections UPS Input ~ Bypass Input ~ Output ~ UPS Feed Bypass Feed Figure 7 Hardwire terminals Jumper removed for clarity 3.6.1 Input and Output Connection Requirements • Any 120V loads must be distributed evenly between X1-X2, X1-X4 and X4-X2. Do not connect loads between X3-X2 or between X3-X4—these are not standard voltages. -
Page 15: Connecting Power Cables
™ . A cable to connect the battery cabinet and the Liebert GXT3-10000T220 is supplied with each battery cabinet. Open the breaker before making battery cable connections. Plug one end of this cable into the UPS and the other end into the battery cabinet—slotted fittings on each end ensure that the connection is properly made. -
Page 16: Operation
Operation PERATION Block Diagram ® The Liebert GXT3-10000T220 consists of the following main components: ™ • 2 utility inputs with separate breakers—utility and bypass • rectifier/booster, inverter and charger • electronic bypass • 2-position Maintenance Bypass Breaker—UPS and BYPASS • integrated battery... -
Page 17: Control Panel
Operation Control Panel The Control Panel’s LCD and buttons are used to initiate various UPS operations, tests and commands and to view the status of the UPS. By pressing the Menu Up or Menu Down and Enter keys , it is possible to scroll through the various menus. -
Page 18: Figure 11 Menu Tree
Operation Figure 11 Menu tree Turn UPS On/Off Battery Alarm Test Control Control Battery Battery Test Test Contrast Battery Test Status Audible Alarm Output Start Voltage Parallel Window Menu Battery Pack System Battery Main Test Status Interval Setup DC Start Address Parallel Model... -
Page 19: Table 3 Displayed Text-System Block And Main Menu
00000-99999 Language English/French/Spanish/German/Italian/ Russian Event and time Logging Clear event log Menu * : Max 4 fault event record ® ™ Type of UPS Liebert GXT 10KVA Liebert GXT3-10000T220 Capacity 10KVA Firmware Internet IP Web: www.liebert.com Version Software Display Firmware... -
Page 20: Battery Setup Parameters
Operation Table 3 Displayed text—system block and main menu (continued) Item # and Name Description Turn UPS ON/OFF Turn UPS to ONLINE Turn UPS to BYPASS Turn UPS to shutdown Turn UPS to no output Alarm control Alarm ON Control Alarm OFF Menu Batt Test... -
Page 21: Fault Indicators
Operation 4.2.4 Fault Indicators If a fault occurs, the UPS automatically switches to BYPASS mode, ONLY in case of a battery disconnect fault will the original operating mode be maintained. The fault message alternates with UPS mode once a second, the red Fault LED illuminates on the control panel and the buzzer sounds continuously. -
Page 22: Initial Ups Startup Procedure
Operation Initial UPS Startup Procedure 1. Inspect all power connections to ensure they are correct and secure. 2. Open external circuit breakers/fused disconnects to the connected loads. 3. Close all upstream circuit breakers and fused disconnects. 4. Use a voltmeter to verify proper input voltage is present on the UPS and Bypass input terminals. See Table 9 for the range. -
Page 23: Return From Maintenance Bypass
The load is not protected against any utility disturbances or interruptions while the UPS is in bypass mode. 1. With the Liebert GXT3-10000T220 connected to the utility, press the Menu button, select Control and press OK. 2. Select Turn UPS On/Off and press OK. -
Page 24: Maintenance
GXT3 is designed to allow the user to replace the internal battery pack safely. Refer to ® ™ Table 7 for internal battery pack part numbers for Liebert GXT3 UPS and Liebert External Battery Cabinets: Table 7 Replacement battery pack... -
Page 25: Communication
When the Auto-enable output option is selected and the UPS output is disabled using the pins in Set 3, the Liebert GXT3-G’s output can turn On automatically and without warning if the connection of the pins in Set 3 is changed. -
Page 26: Battery Mode Shutdown
This timer cannot be stopped once triggered. If the utility power returns during this countdown, the Liebert GXT3 will still shut down and must remain shut down for 10 seconds. Whether the UPS turns back On when the power is restored depends on the auto-restart setting. -
Page 27: Liebert ® Multilink
6.3.1 Liebert MultiLink Liebert MultiLink continually monitors the UPS and can shut down your computer or server in the event of an extended power failure. ® Liebert MultiLink can also be configured for use without the USB cable when the Liebert IntelliSlot SNMP/Web card is installed in the UPS. -
Page 28: Troubleshooting
Troubleshooting ROUBLESHOOTING If any technical problems should occur, check the following before contacting Liebert ® technical support: • Is the utility voltage present at the UPS input? • Has the input fuse blown or have the circuit breakers tripped? • Has the UPS startup procedure been followed correctly? When contacting Liebert technical support, have the following information available: •... -
Page 29: Specifications
Specifications PECIFICATIONS ® ™ Table 9 Liebert GXT3 specifications 10,000 (9000) Model Rating, VA (W) Dimensions, in. (mm) Unit, W x D x H 31.5 x 11.81 x 26.57 (800 x 300 x 675) Shipping, W x D x H 41.8 x 16.7 x 34 (1062 x 426 x 866) -
Page 30: Table 10 Battery Cabinet Specifications
Up to 3281 ft (1000m) at 80°F (27°C) without derating Agency Safety UL 1778, c-UL Listed Transportation ISTA Procedure 1B ® ™ Table 11 Typical battery run times for the Liebert GXT3-10000T230 Load % Number of Batteries, Battery Cabinets 100% Internal Battery Internal Battery + 1 External Battery Cabinet... -
Page 31: Product Warranty Registration
RODUCT ARRANTY EGISTRATION To register for warranty protection: • Visit the Quick Links section of Liebert’s Web site at: http://www.liebert.com • Click on Product Warranty Registration and fill in the form. If you have any questions, please contact us at: •... - Page 32 +39 049 9719 111 Fax: +39 049 5841 257 While every precaution has been taken to ensure the accuracy and completeness of this literature, Liebert Corporation assumes no Asia responsibility and disclaims all liability for damages resulting from use of 29/F, The Orient Square Building this information or for any errors or omissions.
