Contents

For contents, please refer to the contents sheet.

Quick Start

To connect the LCD monitor to your system, follow these instructions:
NOTE: Make sure to read "Recommended Use" (page 3) before installation.
The accessories included will depend on the where the LCD monitor is to be shipped.
Do not hold Tilt cover. It can damage tilt cover.
1. Turn off the power of your computer.
2. For a PC with DisplayPort output: Connect the DisplayPort cable to the connector of the display card in your system
(Figure A.1).
For a PC with HDMI output: Connect the HDMI cable to the connector of the display card in your system (Figure A.2).
For a MAC with Thunderbolt or Mini DisplayPort output: Connect a Mini DisplayPort to DisplayPort cable to a
video connector in your system.
An alternative is to use an approved Mini DisplayPort to DisplayPort cable to connect the computer to the display
(Figure A.3).
DisplayPort cable
Figure A.1
NOTE: 1. When removing the DisplayPort cable, hold down the top button to release the lock.
2. Please use a High Speed HDMI cable with HDMI logo.
3. Please use a DisplayPort Certifi ed DisplayPort cable.
3. Place hands on each side of the monitor to tilt the LCD panel 30-degree angle and lift up to the highest position.
HDMI cable
Figure A.2
English-5
Figure A.3
