TILE MATRIX ENABLE
Allows one image to be displayed over multiple screens. This feature can be used with up to 25 monitors (5 vertical
and 5 horizontal). Using TILE MATRIX ENABLE requires the PC output signal be sent through a distribution amplifi er
to each individual monitor.
TARGET MONITOR NO.
Controls sub monitor's OSD by using master monitor's control keys.
Sets the sub monitor number that is set at MONITOR NO. By touching INPUT (SELECT) key, each sub monitor
displays its monitor number.
The sub monitor who is set as a target monitor is shown yellow in OSD. Please refer to ControlSync (see page 10)
about the relation of master monitor and sub monitors.
INDIVIDUAL ADJUST
ON: Controls sub monitor by master monitor.
Once ON is set, operation at master monitor refl ects to sub monitor OSD.
To disable INDIVIDUAL ADJUST, please touch SELECT and EXIT keys simultaneously.
NOTE: Please connect monitors with ControlSync cable.

ECO Information

CARBON SAVINGS: Displays the estimated carbon savings information in kg.
CARBON USAGE: Displays the estimated carbon usages information in kg. This is the arithmetic estimation, not
actual measurement value.
COST SAVINGS: Displays the electricity cost savings in balance.
CARBON CONVERT SETTING: Adjusts the carbon footprint factor in the carbon saving calculation. This initial setting
is based on the OECD (2008 Edition).
CURRENCY SETTING: Displays electricity pricing in 6 currency units.
CURRENCY CONVERT SETTING: Displays electricity savings in kW/hour (US Currency is default).
NOTE: This model's initial setting is "Currency = US$" and its Currency Convert setting = $0.11.
This setting can be changed by using the ECO information menu.
If you want to use the French setting, please refer to steps below:
1. Touch the Menu key and select the ECO information menu using the LEFT/RIGHT key.
2. Select CURRENCY SETTING item by moving the DOWN/UP key down or up.
3. The French currency unit is Euro ( ). You can adjust currency setting to Euro icon ( ) from US dollar ($)
by moving the LEFT/RIGHT key left or right in Current setting item.
4. Select CURRENCY CONVERT SETTING by moving the DOWN/UP key down or up*.
5. Adjust CURRENCY CONVERT SETTING by moving the LEFT/RIGHT key left or right.
* This initial Euro ( ) setting is Germany of OECD (2007 Edition).
Please check receipt of French's electricity prices or OECD data for French.
French of OECD (2007 Edition) was
Information
Provides information about the current resolution display and technical data including the preset timing being used and
the horizontal and vertical frequencies. Indicates the model and serial numbers of your monitor.
OSD Warning
OSD warning menus disappear when EXIT is selected.
NO SIGNAL: This function gives a warning when there is no horizontal or vertical sync. After power is turned on or
when there is a change of input signal, the NO SIGNAL window will appear.
OUT OF RANGE: This function gives a recommendation of the optimized resolution and refresh rate. After the power
is turned on or there is a change of input signal or if the video signal doesn't have proper timing, the OUT OF RANGE
menu will appear.
0.12.
