FOREWORD
This manual contains
troubleshooting instructions and parts list for your new
Jacobsen machine. This manual should be stored with
the equipment for reference during operation.
Before you operate your machine, you and each operator
you employ should read the manual carefully in its
entirety. By following
maintenance instructions, you will prolong the life of your
equipment and maintain its maximum efficiency.
If additional information is needed, contact your
Jacobsen Dealer.
Suggested Stocking Guide
To Keep your Equipment fully operational and productive, Jacobsen suggests you maintain a stock of the more
commonly used maintenance items. We have included part numbers for additional support materials and training aids.
To order any of the following material:
1. Write your full name and complete address on your
order form.
2. Explain where and how to make shipment:
UPS
Overnight
Qty. Part No.
4177262 Engine Oil Filter
2198147-01 Engine Air Filter
2721539-01 Engine Fuel Filter
5001182 Pre-Fuel Filter
Qty. Part No.
4201281 Safety & Operation Manual
4201280 Parts & Maintenance
These are the original instructions verified by
Jacobsen, A Textron Company.
© 2010, Jacobsen, A Textron Company/Textron Innovations Inc.
"All rights reserved, including the right to reproduce this material
or portions thereof in any form."
en-2
adjustment, maintenance,
the safety, operating
Regular Mail
2nd Day
Description
Description
Litho In U.S.A. 5-2012
The serial plate is located on the right frame rail.
Jacobsen recommends you record these numbers below
for easy reference.
and
3. Order by the quantity desired, the part number, and
the description of the part.
4. Send or bring the order to your authorized Jacobsen
Dealer.
Qty. Part No.
178025 Hydraulic Oil Filter
Service Support Material
Qty. Part No.
4171722 Service Manual
4191628 DVD, Operator Training
This
chemicals known to State of Cal ifornia
to cause cancer and birth defects or
other reproductive harm.
