Parts & Maintenance Manual
Ersatzteil- und Wartungshandbuch
HR 9016 Turbo
Sichelmäher HR 9016 Turbo
70538 – Kubota V3800DICR-T-E3B, 4WD*
70539 – Kubota V3800DICR-T-E3B, 4WD with ROPS
70540 – Kubota V3800DICR-T-E3B, 4WD EC with ROPS
70541 – Kubota V3800DICR-T-E3B, 4WD EC*
70538 – Kubota V3800DICR-T-E3B, 4-Radantrieb*
70539 – Kubota V3800DICR-T-E3B, 4-Radantrieb mit ROPS (Überrollschutz)
70540 – Kubota V3800DICR-T-E3B, 4-Radantrieb EC mit ROPS (Überrollschutz)
70541 – Kubota V3800DICR-T-E3B, 4-Radantrieb EC*
*- These units must have a certified ROPS/cab installed by the Dealer before the mower can be put into service and registered for warranty coverage.
*- Bei diesen Maschinen muss vom Händler ein zertifizierter Überrollbügel (ROPS)/ Kabine montiert werden, bevor der Mäher in Betrieb genommen werden und für
Garantieleistungen registriert werden kann.
WARNING: If incorrectly used this machine can cause severe injury.
Those who use and maintain this machine should be trained in its
proper use, warned of its dangers and should read the entire manual
before attempting to set up, operate, adjust or service the machine.
ACHTUNG: Wenn diese Maschine nicht ordnungsgemäß verwendet
wird, können ernsthafte Verletzungen verursacht werden. Personen,
die diese Maschine verwenden und warten, müssen in ihrer richtigen
Verwendung ausgebildet sein, auf die Gefahren aufmerksam
gemacht worden sein und die Anleitung ganz gelesen haben, bevor
sie versuchen, die Maschine aufzustellen, zu bedienen, einzustellen
oder zu warten.
GB
DE
United
Germany
Kingdom
Rotary Mower
WARNING
ACHTUNG
4228362-DE-Rev A
When Performance Matters.
6
5
9
1 1
1 6
1 3
1 5
7
8
1 8
1 - I N C L U D E S I T E M S 3 - 1 6
1 7
1 9
3
1 0
4
