Safety, Operation, & Maintenance Manual
®
Turfcat
with ROPS
69168 – Turfcat T628D, D1305-E3B, 2WD
69169 – Turfcat T628D, D1305-E3B, 4WD
69175 – Turfcat T628D, D1305-E3B, 2WD
69176 – Turfcat T628D, D1305-E3B, 4WD
69184 – Turfcat T628D, D1105-E4B, 2WD
69185 – Turfcat T628D, D1105-E4B, 4WD
WARNING
Warning: If incorrectly used, this machine can
cause severe injury. Those who use and maintain
this machine should be trained in its proper use,
warned of its dangers, and must read the entire
manual before attempting to set up, operate, adjust,
or service the machine.
GB
4201281-Rev B
