Data Logger
Id. Alarm Description
Mains Failure
8.3
Battery Discharging
Mains Failure:
8.2
Battery Low Level
Input Voltage Wrong:
8.1
Rectifier Stop
Inverter
8.0
Overload
Bypass Failure: Not
7.9
Synchronised Inverter
Measures Alarms
Fig. 14. Data logger alarms.
These alarms have an identifier or "Id" displayed in the first
column of the «Data logger» table. The second column displays
the description of the triggered alarm and the third column
displays the start and end dates of this alarm. The next columns
show the status of the PFC, inverter, equipment in parallel and
UPS, when the alarm was triggered. Finally, the column labelled
as "Flag Code", it is an internal code of the equipment.
The «Backward» key will go back the end-user
1.
Back

to the «Alarms» screen.
The «Down» key allows going to the next page, which
2.

will display the oldest alarms in the data logger.
The «Up» key allows going to the previous page,
3.

which will display the most recent alarms in the
data logger.
4.3. STATUS AND CONTROL.
The «Status and Control» touch icon is located in the bottom
area, in the third position of main menu.
When touching the graphic, the status of the different
Status - Control
parts of the UPS are shown in the centre of the screen.
UPS status.
•
Battery test status.
•
ECO-Mode status.
•
In the side bar of the same screen there are four graphics as a
buttons, three of «Start/Stop» and one to set the «Battery Test
properties». They are displayed in the following order:
Start / Stop
Touch button to start up or shutdown the UPS.
1.
UPS
Start / Stop
Touch button to start the UPS battery test.
2.
Batt. Test
Batt. Test
To get useful and operating information, see
3.
Features
section 4.3.1.
Start / Stop
Touch button used to put the UPS on Smart
4.
ECO-Mode
ECO-Mode (loads are supplied through the
static bypass line directly, less in case of mains
failure or out of limits).
USER'S MANUAL
Flag
Date PFC Inverter Parallel UPS
Code
27/11/16 - 00:50:17
OFF OFF INI READY 4
27/11/16 - 00:50:37
27/11/16 - 00:50:12
OFF OFF INI READY 0
27/11/16 - 00:50:37
27/11/16 - 00:50:12
OFF OFF INI READY 4
27/11/16 - 00:50:37
26/11/16 - 09:54:11
WCTT OFF INI BYPASS 0
26/11/16 - 09:54:13
22/11/16 - 13:52:16
OFF OFF INI READY 0
22/11/16 - 13:52:22
Status - Control Rated Values Plots
When touching over any touch «Start/Stop» graphic, a dialogue
"Pop up" window will be displayed, by asking the end user if
Back
the selection is the correct one (see Fig. 15).
Page
Fig. 15. Pop up requesting confirmation.
1/20
Advanced

4.3.1. Battery test features.

Batt. Test
This touch button allows setting the battery test
Features
parameters. When entering into this menu, there
are two blocks, «Automatic Test Class» and «Battery
Test Programming: Date and Time».
The «Drop-down» list button allows, depending on
1.
the field, opening the menu and selecting one of the
proposed variables or entering a value through the
pop up keyboard, in order to change it. When touching
one of the fields, a "Pop up" window will be dis-
played, which allows one of these two options.
4.4. NOMINAL VALUES.
The «Nominal values» touch icon is located in the bottom area,
in the fourth position of main menu.
By means of this button the following nominal
Rated Values
values of the UPS can be checked:
Input voltage.
ˆ
Output voltage.
ˆ
Lower input voltage range.
ˆ
Upper input voltage range.
ˆ
Battery charging current.
ˆ
Output current.
ˆ
Bypass voltage.
ˆ
Lower bypass voltage range.
ˆ
Upper bypass voltage range.
ˆ
Inverter voltage.
ˆ
DC bus voltage.
ˆ
The «Down» key allows going to the next page, of
1.

parameters, which will display more nominal values.
The «Up» key allows going to the previous page, of
2.

parameters, which will display more nominal values.
4.5. PLOTS.
The «Plots» touch icon is located in the bottom area, in the fifth
position of main menu.
By means of this button as an icon mode, two
Plots
different ways of data logger visualisation can be
displayed (see Fig. 16 and 17), but in both cases,
four parameters only.
Are you sure?
YES NO
SLC CUBE3+ CONTROL PANEL WITH TOUCH SCREEN
13
