Contents
1. Important Safety Instructions ...................................................................... 2
2. Package Contents and Technical Specifications ...................................... 6
2.1 Package Contents .................................................................................... 6
........................................................................................... 6
2.3 Product Diagram....................................................................................... 7
3. Operating and Programming ....................................................................... 9
3.1 Notes Before Cleaning ............................................................................. 9
3.2 Quick Start .............................................................................................. 10
3.3 Cleaning Pattern and Cleaning Mode Selection .................................... 13
3.4 Programming the Robot ......................................................................... 15
3.5 Optional Mopping System ...................................................................... 15
3.6 Choosing a Suction Option ..................................................................... 17
3.7 Alarm Indicator Light and Sounds .......................................................... 19
4. Maintenance ................................................................................................ 20
4.1 Dust Bin and Filters ................................................................................ 20
4.4 Other Components ................................................................................. 23
4.5 Regular Maintenance ............................................................................. 24
5. Troubleshooting ......................................................................................... 25
.................................... 21
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DD4G and is the answer not in the manual?

Questions and answers

Related Manuals for ECOVACS DD4G

Summary of Contents for ECOVACS DD4G

  • Page 1: Table Of Contents

    Contents 1. Important Safety Instructions ..............2 2. Package Contents and Technical Specifications ........6 2.1 Package Contents ..................6 ................... 6 2.3 Product Diagram..................7 3. Operating and Programming ............... 9 3.1 Notes Before Cleaning ................9 3.2 Quick Start ....................10 3.3 Cleaning Pattern and Cleaning Mode Selection ........

  • Page 2: Important Safety Instructions

    1. Important Safety Instructions When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE. SAVE THESE INSTRUCTIONS 1. This Appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the...
  • Page 3 1. Important Safety Instructions 9. Do not operate the Appliance in an area where there are lit candles or fragile objects. 10. Do not use in extremely hot or cold environments (below 11. Keep hair, loose clothing, fingers, and all parts of body away from any openings and moving parts.
  • Page 4 28. When not using the Docking Station for a long period of time, please unplug it. 29. The Appliance must be used in accordance with the directions in this Instruction Manual. ECOVACS ROBOTICS cannot be held liable or responsible for any damages or injuries caused by improper use.
  • Page 5 1. Important Safety Instructions 35. Different types of batteries or new and used batteries are not to be mixed. 36. Batteries of the Remote Control are to be inserted with the correct polarity. 37. Exhausted batteries are to be removed from the Appliance and safely disposed of.

  • Page 6: Package Contents And Technical Specifications

    Main Brush Option Direct Suction Option Reservoir (Pre-installed) (2) Washable/Reusable Cleaning Cloth Plate Sponge Filter and 2.2 Specifications Model DD4G, DD4G.**(*=0-9) Working Voltage 12V DC Rated Power Docking Station Model CH1630A Rated Input Voltage 100-240V AC Rated output voltage 20V DC Rated Output Current 0.8A...

  • Page 7: Product Diagram

    2. Package Contents and Technical Specifications 2.3 Product Diagram Robot 1. Cover 7. Side Brushes 14. RESET Button 2. AUTO Mode Button 8. Main Brush Option 15. Power Switch 3. Bumper with Anti- 9. Driving Wheels 16. Dust Bin Collision Sensors 10.
  • Page 8 2. Package Contents and Technical Specifications Advanced Mopping System 1. Water Inlet 2. Reservoir 3. Cleaning Cloth Plate Cleaning Cloth 5. Magnet Docking Station 1. Infrared Signal Generator 2. Docking Station Pins Remote Control 1. START/PAUSE Button 2. Direction Control Buttons 3.

  • Page 9: Operating And Programming

    3. Operating and Programming 3.1 Notes Before Cleaning Before operating DEEBOT, take a few moments to survey the area to be cleaned and remove any obstacles. Please take care of DEEBOT and assist it at Before using the product near an area rug or on a short-pile area rug with tasseled edges, please fold area rug edges under themselves.

  • Page 10: Quick Start

    3. Operating and Programming Please be aware that the robot needs at Please do not stand in narrow spaces, such as least an 8 cm (3.1") clearance to clean under hallways, or DEEBOT may fail to identify the furniture without complications. area to be cleaned.
  • Page 11 3. Operating and Programming Docking Station Placement Place the Docking Station on a level floor surface against the wall with the base perpendicular to the ground. Keep the immediate area 1.5m (5') in front of the charger and 0.5m (1.6') on both sides of the charger clear of objects and Plug the Docking Station in.
  • Page 12 3. Operating and Programming Charge DEEBOT Place DEEBOT on the Docking Station making sure the Charging Contacts on DEEBOT and the Docking Station Pins make a connection. Charge DEEBOT for at least 4 hours before * Make sure to turn the robot’s Power Switch to the ON position before charging. * AUTO Mode Button blinks when DEEBOT is charging.

  • Page 13: Cleaning Pattern And Cleaning Mode Selection

    * When DEEBOT is not cleaning, it is suggested to keep it powered ON and charging. * For models with app-connectivity, various functions can be performed using the ECOVACS App. 3.3 Cleaning Pattern and Cleaning Mode Selection DEEBOT has 2 Cleaning Patterns and several cleaning modes to choose from to effectively clean different floors.
  • Page 14 Double-click the AUTO Button on the robot. Cleaning Pattern is switched when DEEBOT emits two beeps. Cleaning Patterns can also be set using the ECOVACS App. DEEBOT uses the set Cleaning Pattern when cleaning in AUTO Cleaning Mode. Select Cleaning Mode...

  • Page 15: Programming The Robot

    In Edge Cleaning Mode, DEEBOT cleans along a border (e.g. wall). 3.4 Programming the Robot ECOVACS App. 3.5 Optional Mopping System DEEBOT has an optional Mopping System using a Washable/Reusable Microfiber Cleaning Cloth and Cleaning Cloth Plate attached to a proprietary Reservoir. The washable/reusable Cleaning Cloth automatically damp mops the floor to a spotless clean.
  • Page 16 3. Operating and Programming Add Water into the Reservoir. Attach Cleaning Cloth; Install the Cleaning Cloth Plate and the Reservoir. Start Select the desired Cleaning Mode. DEEBOT sweeps, lifts, vacuums and mops in the selected mode.

  • Page 17: Choosing A Suction Option

    3. Operating and Programming 3.6 Choosing a Suction Option The robot has 2 interchangeable suction options for your convenience. Main Brush Option: The best choice for deep Direct Suction Option: The best choice for cleaning with a combination of the Main Brush daily cleaning with the Main Brush removed for and strong suction.
  • Page 18 3. Operating and Programming Install the Main Brush Option Turn the robot over. Push both buttons on the Direct Suction Option and remove Direct Suction Option. Insert the Main Brush into the bottom of the robot. Line up the Main Brush Cover tabs with the slots on the bottom of the robot. Press until the component clicks into place.

  • Page 19: Alarm Indicator Light And Sounds

    3. Operating and Programming 3.7 Alarm Indicator and Sounds If DEEBOT detects a problem and needs your assistance, it emits alarm beeps or the Status Indicator Light illuminates. Alarm Sound Indicator Light Problems Solution Status Indicator Power ON the robot. Manually DEEBOT has low and goes out place the robot on the Docking...

  • Page 20: Maintenance

    4. Maintenance Before performing cleaning and maintenance, power OFF DEEBOT and unplug the Docking Station. 4.1 Mopping System After DEEBOT finishes mopping, remove the Reservoir from DEEBOT, and maintain the Reservoir, the Cleaning Cloth and the Cleaning Cloth Plate immediately. Press the Release Button and pull to remove the Reservoir.

  • Page 21: Dust Bin And Filters

    4. Maintenance 4.2 Dust Bin and Filters Open the robot’s Top Cover and remove the Dust Bin. Open the Dust Bin Cover and empty the Dust Bin.

  • Page 22: Main Brush, Direct Suction Option And Side Brushes

    4. Maintenance Rinse the Sponge Filter, Dust Bin and Filter Net under running water. reinstalling. 4.3 Main Brush, Direct Suction Option and Side Brushes * A Multi-Function Cleaning Tool is provided for easy maintenance. Handle with care, this cleaning tool has sharp edges. Main Brush Turn the robot over.

  • Page 23: Other Components

    4. Maintenance Cleaning the Side Brushes Remove the Side Brushes. Remove any hair or debris tangled around the Side Brushes with the provided Multi-Function Cleaning Tool, and wipe their slots with a clean cloth. 4.4 Other Components Use the Multi-Function Cleaning Tool to cut off and remove any hair tangled around the Universal Wheel.

  • Page 24: Regular Maintenance

    Sponge Filter/ High Once per week (twice per Every 4-6 months Universal Wheel Anti-Drop Sensors Bumper Once per week Charging Contacts Docking Station Pins Note: ECOVACS manufactures various replacement parts and assemblies. Please contact Customer Service for more information on replacement parts.

  • Page 25: Troubleshooting

    5. Troubleshooting Please use this chart to troubleshoot common problems using DEEBOT. Malfunction Possible Causes Solutions DEEBOT is not powered Move the robot’s Power Switch to the ON position. Be sure that the robot’s Charging DEEBOT has not made a Contacts have made a connection with connection with the Docking the Docking Station Pins.
  • Page 26 5. Troubleshooting Malfunction Possible Causes Solutions Intelligent Scheduling or Time Scheduling function is Please refer to section 3.4 for details. cancelled. DEEBOT is powered OFF. Power ON DEEBOT. DEEBOT will not clean automatically at Keep DEEBOT powered ON and on scheduled time.
