Summary of Contents for ECOVACS DEEBOT T10 PLUS
- Page 1 Instruction Manual...
- Page 2 Important Safety Instructions 3. If there is a drop off in the cleaning area due to a step or stairs, you should operate the IMPORTANT SAFETY INSTRUCTIONS Appliance to ensure that it can detect the When using an electrical Appliance, basic step without falling over the edge.
- Page 3 10. Do not use in extremely hot or cold environments 18. Take care not to damage the power cord. Do (below -5˚C/23˚F or above 40˚C/104˚F). not pull on or carry the Appliance or Empty 11. Keep hair, loose clothing, fingers, and all Station by the power cord, use the power parts of body away from any openings and cord as a handle, close a door on the power...
- Page 4 Instruction Manual. Some devices, especially those that went on sale ECOVACS ROBOTICS cannot be held liable more than three years ago, will only be updated if or responsible for any damages or injuries a critical vulnerability is found and fixed.
- Page 5 For EU Declaration of Conformity information, visit Please be aware of the local data protection based https://www.ecovacs.com/global/compliance . legal obligations in case of use. No surveillance of public places, especially with clandestine intent For UK...
-
Page 6: Package Contents
Figures and illustrations are for reference only and may differ from actual product appearance. Product design and specifications are subject to changes without notice. * Air Freshener Capsule is sold separately that works with Air Freshener. Explore more accessories at https://www.ecovacs.com/global. - Page 7 Bottom View Carpet Detection Universal Wheel Microphone Sensor Wi-Fi Status Dual Side Brushes Indicator RESET Button Floating Main Brush Power Switch Driving Wheels Anti-drop Sensors Auto-Empty Dust Bin Auto-Empty Dust Bin Handle Floating Main Brush Release Button High Efficiency Filter Anti-drop Sensors Air Freshener Filter Net...
- Page 8 Empty Station Top Cover Storage Box Charging Contacts Indicator Light OZMO™ Pro 3.0 Oscillating Mopping System Charging Contacts Water Inlet Reservoir Auto-Empty Inlet Reservoir Release Button Air Freshener (Pre-installed) Capsule Container Empty Station (Top) Air Freshener Dust Bag Socket Release Button Dust Evacuation Tube Blower Cover...
-
Page 9: Notes Before Cleaning
Empty Station (back) Notes Before Cleaning Tidy up the area to be cleaned by putting furniture, such as chairs, in their proper place. During the first use, make sure each room door is open to help DEEBOT fully explore your house. It may be necessary to place a physical barrier at the edge of a drop to stop the Power Cord Port... -
Page 10: Quick Start
Disconnected to Wi-Fi or Slowly flashing the aforementioned intelligent functions cannot be realized through waiting for Wi-Fi connection ECOVACS HOME App, but you can still use the basic functions of Rapidly flashing Connecting to Wi-Fi this product for manual operation. - Page 11 Charging DEEBOT Power ON Connect the Power Cord Note: I = ON, O = OFF. DEEBOT cannot be charged when being powered OFF. Empty Station Placement and Assembly Note: Please do not place the Empty Station on the carpet. Charge DEEBOT Keep the area around the Station clear of objects and reflective object surfaces.
- Page 12 During the first cleaning: 1. Please make sure to install Air Freshener to create a home map,including carpet area in ECOVACS HOME App 2. Please ensure that DEEBOT is fully charged. 3. Please supervise DEEBOT and assist it should there be a problem.
- Page 13 Click * To prolong the service life of OZMO™ Pro 3.0 Oscillating Mopping System, it is recommended to use purified water or ECOVACS DEEBOT Cleaning Solu- tion. Explore more accessories at https://www.ecovacs.com/global. * Do not soak OZMO™ Pro 3.0 Oscillating Mopping System in water.
-
Page 14: Air Freshener
Air Freshener Install Air Freshener Install Air Freshener Capsule (sold separately) Click... -
Page 15: Regular Maintenance
Before performing cleaning and maintenance tasks on DEEBOT, turn the robot OFF and unplug the Empty Station. A multi-function Cleaning Tool is provided for easy maintenance. Handle with care, this cleaning tool has sharp edges. Note: ECOVACS manufactures various replacement parts and fittings. Please contact Customer Service for more information on replacement parts. - Page 16 Maintain OZMO™ Pro 3.0 Oscillating Mopping System Remove OZMO™ Pro 3.0 Oscillating Mopping System Washable Mopping Pad * After DEEBOT finishes mopping, please empty the reservoir. Wipe OZMO™ Pro 3.0 Oscillating Mopping System Clean * Wipe OZMO™ Pro 3.0 Oscillating Mopping System with a clean, dry cloth. Do not soak into water.
- Page 17 Maintain Auto-Empty Dust Bin Disposable Mopping Pad and Filters...
- Page 18 Maintain Floating Main Brush and Dual Side Brushes Floating Main Brush Note: 1. Please rinse the filter with water as shown above. 2. Do not use finger or brush to clean the filter.
- Page 19 Maintain Empty Station Dual Side Brushes Note: Before performing cleaning and maintenance on Empty Station, unplug it first. * For a proper maintenance, wipe with a clean dry cloth, and avoid using any detergent or cleaning spray. Charging Contacts...
- Page 20 Dust Bag Dispose the Dust Bag * Hold the Handle to lift out the Dust Bag, which can effectively prevent dust leakage. Clean the Blower Cover Install the Dust Bag Close the Dust Container Lid...
- Page 21 Maintain Other Components Note: Wipe the components with a clean, dry cloth. Avoid using cleaning sprays or detergents.
- Page 22 Empty Station The light effect of the Status Indicator on Empty Station corresponds to different conditions and solutions. For more support, please refer to ECOVACS HOME App or the Troubleshooting Section of this manual. Light Effect Status Solutions The Empty Station is in standby.
-
Page 23: Troubleshooting
HOME App. prompt. Incorrect App installed. Please download and install ECOVACS HOME App. DEEBOT does not support 5GHz network. Please use a Not using a 2.4GHz or 2.4/5 GHz mixed network. 2.4GHz or 2.4/5 GHz mixed network. - Page 24 DEEBOT gets stuck while working and stops. DEEBOT might be stuck under furniture with an Please set a physical barrier, or set a Virtual Boundary in entrance of similar height. the ECOVACS HOME App.
- Page 25 Malfunction Possible Causes Solutions Please tidy up the scattered wires, slippers and other objects on the ground before cleaning. And reduce the scattered objects on Objects such as wires and slippers placed on the the ground as far as possible. If there is any area leakage, DEEBOT ground affect the normal operation of DEEBOT.
- Page 26 This is normal. returning to the Empty running Video Manager in the App. Station. Do Not Disturb mode is enabled in ECOVACS This is normal. Disable Do Not Disturb mode in the App, or HOME App. start auto-emptying manually. The Dust Bag is full.
- Page 27 Objects have fallen into the Air Freshener. Please contact Customer Service for assistance. abnormal noise. If it is beyond the available distance, the ECOVACS HOME DEEBOT is too far away from the Station. App can also be used to operate DEEBOT.
-
Page 28: Technical Specifications
Rated Output Power(Auto-Emptying) 1000W Frequency bands 2400-2483.5MHz Networked Standby Power Less than 2.00W Output power of the Wi-Fi module is less than 100mW. Note: Technical and design specifications may be changed for continuous product improvement. Explore more accessories at https://www.ecovacs.com/global. - Page 29 Ecovacs Robotics Co., Ltd. No.518 Songwei Road, Wusongjiang Industry Park, Guoxiang Street, Wuzhong District, Suzhou, Jiangsu, China. 451-2113-0300...
