Connector - Visual inspection (J.80.B.66 - F.40.A.10)

435, 445, 445CT

1. Inspect the coupler frame (1) to be sure it is free of
cracks, corrosion, rust or any other damage. Use
new parts as required.
2. Inspect the upper pins (15) and the lower pins (16)
for wear, cracks, corrosion or any other damage.
Use new parts as required.
3. Inspect the lock pins (14) for wear and damage.
Use new parts as required.
4. Inspect the link rod (13), spring (10), spring guide
(9) and trunnion (8) for wear and damage. Use new
parts as required.
5. Inspect the left handle (2) and the right handle (3)
for wear and damage. Use new parts as required.
TOOLS AND COUPLERS - COUPLING Mechanical coupling
1 04/05/2005
J.80.B / 7
