Connector - Disassemble (J.80.B.66 - F.10.A.25)

435, 445, 445CT

1. Loosen and remove the nut (20), bolt (17), two
washers (19) and spacer from the left and right
lower pins of the coupler frame (1).
2. Use acceptable tools and remove the left and the
right lower pins (16) from the coupler frame (1).
3. Remove the nut (20), bolt (17), two washers (19)
and spacer (18) from the left and right upper pins
(15) of the coupler frame (1).
4. Use acceptable tools and remove the left and right
upper pins (15) from the coupler frame (1).
5. Remove the coupler frame (1) from the loader arms.
Remove the coupler frame (1) on the work bench.
6.
7. Remove one cotter pin (12) from the clevis pin (11).
Remove the clevis pin (11) from the lock pin (14).
8. Remove the retaining ring (6) from the left handle
(2). Lift the left handle (2) until the link rod (13)
disengages the lock pin (14). Remove the left
handle (2) and wave spring (5) from the coupler
frame (1). Remove the lock pin (14) from the
coupler frame (1).
9. Place the left handle (2) in a vise with soft jaws.
10. Prevent the link rod (13) from turning. Loosen
and remove the lock nut (7) from the link rod (13).
Remove the link rod (13), spring (10), spring guide
(9) and trunnion (8) from the left handle (2).
11. Repeat steps 7 through 10 for the right handle (3).
TOOLS AND COUPLERS - COUPLING Mechanical coupling
1 04/05/2005
J.80.B / 3
