1. Coupler frame
2. Protective plate
3. Bolt
4. Washer
5. Lock nut
TOOLS AND COUPLERS - COUPLING Hydraulic coupling
Exploded View of Hydraulic Attachment Coupler
6. Cylinder
7. Clevis pin
8. Cotter pin
9. Snap ring
10. Plate
1
bs04d225
11. Lube fitting
12. Hook wedge
13. Upper pin
14. Lower pin
15. Spacer
1 04/05/2005
J.80.C / 13
16. Right side indicator
17. Left side indicator
