Summary of Contents for Mitox 2700LK PRO
- Page 2 2 ...
-
Page 3: Safety Awareness
in this manual. Congratulations on your purchase of a new MITOX® PRO l E xhaust fumes contain poisonous carbon monoxide gas. ... -
Page 4: Specifications
M odifying the brushcutter may make it unsafe. Never modify your cutting blades only on MITOX® PRO brushcutters equipped with brushcutter, except as advised by MITOX® PRO in writing. Use only ... -
Page 5: Assembly And Preparation
Assembly and Preparation Dealer/Owner Assembly Parts Qty’s Index No. Parts name 3500UK, 4500UK, 2700LUK 2700LK ... - Page 6 Installation of the Double Handle Assembly (2700UK) l R emove the upper bracket (1) from the lower bracket (2) by loosening the bolts (3) with the Allen wrench. l I nstall the handle assembly (4) and the upper bracket into the lower bracket by tightening the 4 bolts.
- Page 7 2700LK 3500LK Installation of Cutting Blade (2700UK) 2700UK l I nsert the Allen wrench (24) into the hole at the gear case cover. l...
-
Page 8: Filling The Tank
NOTE Due to increased Ethanol content in petrol we recommend the use of B3C Ethanol Shield 2-Stroke Oil, and Ethanol Shield Fuel Stabiliser to protect your Kawasaki engine against the harmful effects of Ethanol. -
Page 9: Location Of Parts
Operating Instructions Location of Parts 2700UK 2700LK ... - Page 10 Starting the Engine Double Handle Model (2700UK, 3500UK, 4500UK) l T urn the engine switch (1) to the "I" (ON) position with the throttle lever (2) in the fully closed (Engine idle speed) position.
-
Page 11: Operation
T he carburetor has been adjusted to the optimum fuel supply at the factory. Don't reset the carburetor setting. NOTE ○If adjustment is needed, it performed by your authorized MITOX® PRO dealer. Operation ... -
Page 12: Emergency Stop
Stopping the Engine Ordinary stop CAUTION Suddenly stopping from high-speed operation can cause engine damage. Reduce engine speed to idle for one minute before shutting engine off after high-speed, full-load operation. - Page 13 l P ull the recoil starter grip (1) slowly to engage the starter, then give a short, quick pull. WARNING Recoil starter rope can cause injury if released suddenly. When starting the engine, grasp the recoil starter firmly by the grip. Do not grasp the starter rope itself.
-
Page 14: Maintenance And Adjustment
★ : These items must be performed more frequently as necessary by operating condition. M : These items must be performed with proper tools. See your authorized MITOX® PRO dealer for service. ... -
Page 15: Fuel Filter Service
Fuel Filter Service Clean the fuel filter element every 20 hours. WARNING Improper use of solvents can result in fire or an explosion. Clean the fuel filter in a well-ventilated area away from sources of sparks or flame, including appliances with a pilot light. -
Page 16: Spark Arrester Service
Spark Arrester Service Clean spark arrester every 50 hours of operation. WARNING Hot engine parts can cause severe burns. Allow engine to stop and cool before servicing spark arrester. - Page 17 17 ...
-
Page 18: Troubleshooting Guide
Carbon built-up in combustion chamber Poor ventilation around engine Select a better location. M: Service should be performed by an authorized MITOX® PRO dealer. Environmental Protection To protect our environment, properly dispose of used batteries, engine oil, gasoline, coolant, or other components that you might ... -
Page 19: Ec Declaration Of Conformity
MITOX® Garden Machinery Wincanton Business Park, Wincanton, Somerset, BA9 9RS United Kingdom EC DECLARATION OF CONFORMITY We hereby declare that the following our product conforms to the essential health and safety requirements of EC ... - Page 20 20 ...
