  • Page 1 Operating instructions Vortex flow meter SVxxx4...
  • Page 2: Table Of Contents

    Contents 1 Preliminary note ���������������������������������������������������������������������������������������������������3 1�1 Symbols used ������������������������������������������������������������������������������������������������3 1�2 Warning signs used ���������������������������������������������������������������������������������������3 2 Safety instructions �����������������������������������������������������������������������������������������������3 3 Functions and features ����������������������������������������������������������������������������������������4 4 Function ���������������������������������������������������������������������������������������������������������������4 5 Installation������������������������������������������������������������������������������������������������������������5 6 Electrical connection ��������������������������������������������������������������������������������������������6 7 Operating and display elements ��������������������������������������������������������������������������7 8 Menu ��������������������������������������������������������������������������������������������������������������������8 8�1 Main menu �����������������������������������������������������������������������������������������������������8 8�1�1 Explanation main menu ������������������������������������������������������������������������8 8�2 Extended functions –...
  • Page 3: Preliminary Note

    1 Preliminary note 1.1 Symbols used ► Instructions > Reaction, result […] Designation of pushbuttons, buttons or indications → Cross-reference Important note Non-compliance can result in malfunction or interference� Information Supplementary note� 1.2 Warning signs used CAUTION Warning of personal injury� Slight reversible injuries may result�...
  • Page 4: Functions And Features

    CAUTION For medium temperatures above 50 °C (122 °F) some parts of the housing can heat up to over 65 °C (149 °F)� Risk of burns� ► In this case do not touch the unit� ► Protect the housing against contact with flammable substances and uninten- tional contact�...
  • Page 5: Installation

    5 Installation ► Flow in the direction of the arrow� Observe the installation direction� ► Make sure that pipe and sensor have the same internal diameter� ► Avoid deposits, accumulated gas and air in the pipe system� Install the unit so that the measuring pipe is always completely filled with medium�...
  • Page 6: Electrical Connection

    - For installation using the fixing element: ifm mounting accessories at www�ifm�com� ► Avoid the following installation positions: - Directly in front of a falling pipe� - In a falling pipe� - At the highest point of the pipe system� - Directly in front of the spout of the pipe�...
  • Page 7: Operating And Display Elements

    7 Operating and display elements 1 and 2: LEDs No function 3: TFT display • Display of current process values (volumetric flow quantity, temperature) • Display of the parameters and parameter values 4: Buttons [▲] and [▼] • Select parameters •...
  • Page 8: Menu

    8 Menu 8.1 Main menu Process value display (RUN) ASP1 AEP1 ASP2 AEP2 CFG, MEM, DIS 8.1.1 Explanation main menu ASP1 Analogue start value for temperature AEP1 Analogue end value for temperature ASP2 Analogue start value for volumetric flow AEP2 Analogue end value for volumetric flow Extended functions�...
  • Page 9: 8�2 Extended Functions - Basic Settings

    8.2 Extended functions – basic settings Main menu - - - - l/min Info 0,0...5,0 s IO-L FOU1 FOU2 For SVx6xx units gpm / gph Restoring the factory settings Info Device information IO-L Activate IO-Link communication Submenu basic settings Submenu min/max memory Submenu display settings 8.2.1 Explanation basic settings (CFG) Standard unit of measurement for volumetric flow...
  • Page 10: 8�3 Extended Functions - Min / Max Memory - Display

    8.3 Extended functions – min / max memory – display Main menu 0,0 l/min Lo.F 0,0 l/min Hi.F Info 0,0 °C Lo.T IO-L 0,0 °C Hi.T L1 L2 diS.L d1 d2 d3 diS.U 0 90 180 270 diS.R 25 50 75 100 OFF diS.B coL.F OFF rEd...
  • Page 11: 8�3�1 Explanation Min/Max Memory (Mem)

    8.3.1 Explanation min/max memory (MEM) Lo�F Minimum value of the flow measured in the process Hi�F Maximum value of the flow measured in the process Lo�T Minimum value of the temperature measured in the process Hi�T Maximum value of the temperature measured in the process 8.3.2 Explanation display function (DIS) diS�L Standard layout of the display(L1: flow or L2: flow and temperature)
  • Page 12: 9�1 Parameter Setting In General

    The parameters can also be set via the IO-Link interface� 9.1 Parameter setting in general 1� Change from RUN mode to the main menu [●] 2� Selection of the requested parameter [▲] or [▼] 3� Change to setting mode [●] 4�...
  • Page 13: Factory Setting

    11 Factory setting Parameter Factory setting User setting ASP1 0 % * (TEMP) AEP1 100 % * (TEMP) ASP2 0 % * (FLOW) AEP2 100 % * (FLOW) FOU1 (TEMP) FOU2 (FLOW) col.F (FLOW) col.T (TEMP) l/min (SVx6xx: gpm) 0,6 s diS.L diS.U diS.R...
