OCR 900P Specifications
Frequency of Operation
Sensitivity
Input Carrier Detection Threshold
Carrier Detection Adjustment Step
Carrier Detection Attack Time
Max. Gain Range (Programmable)
On-Channel Repeater
AGC Attack Time
AGC Decay Time
ERP Antenna Output Power
OCR 900P Output Power
Duty Cycle
Output Frequency Stability
Passband Frequency Stability
Modulation Types
Channel Spacing
Selectivity 25kHz / 12.5kHz
Receiver Spurious Response
Rejection
Receiver Intermodulation
Receiver Conducted Spurious
Emissions
Transmitter Conducted Spurious
Emissions
Transmitter FM Hum and Noise
Input / Output Impedance
Input / Output VSWR
Power Supply Voltage
Power Supply Current Drain
Standby
Transmit
RF Connectors
Environmental
Operating Temperature Range
Dimensions [H x D x W]
Weight
8A535X03 Rev. Preliminary-00
ELECTRICAL SPECIFICATIONS
1 to 20 W (Antenna ERP cannot exceed 5W)
900 MHz
(+/- 0.1 ppm With Optional External Ref. Generator)
Narrowband FM Voice, P25 Voice and Data
MECHANICAL SPECIFICATIONS
260 x 225 x 75 mm (10.25" x 8.86" x 2.95")
OCR 900P
931.0125 – 931.9875 MHz
-113 dBm
-113 to -80 dBm
1 dB
<2 ms
70 to 140 dB
< 2 ms
< 2 ms
5W Maximum
100%
Tracks Input Signal Frequency
+/- 1.5ppm
25 kHz / 12.5 kHz
>65 / > 55dB
> 70 dB
> 70 dB
< -57 dBm
< -20 dBm
> 45 dB
50 Ohms
< 2 : 1
22 to 28 VDC
< 0.45 A
< 4 A
SMA female
90% humidity @ 50 °C (122°F)
-30 to +60°C (-22 to +140°F)
4.09 kg (9 lb)
