USING THE PROGRAMMING SOFTWARE FOR SETTING UP THE OCR

STARTING UP THE PROGRAMMING SOFTWARE

After connecting the programming cable to the OCR serial port, run the programming software. The
following screen will be displayed:

USING THE PROGRAMMING SOFTWARE ON-LINE

For successful On-Line operation the OCR needs to be properly connected prior to
commencing the programming / system setup:
1. The OCR must be plugged into the Futurecom subrack and supplied with proper DC
power supply.
2. The RF IN and RF OUT ports need to be connected to the corresponding multicoupling
ports or to adequate power rating 50 Ohm loads (or to the test equipment).
3. The DC power supply needs to be turned on.
For successful On-Line operation, the PC RS232 port has to be properly initialized and connected to
the OCR by using the provided serial cable. The COM port settings need to be specified the first time
you run the programmer on your PC as described below.
Go to the Options pull down menu:
Select Ports / Modem Setup:
If connecting directly to the repeater select Direct Access to unit and ensure the correct COM port is
selected Exit from the Ports menu and select "Yes" when prompted "Would you like to update the
config file?"
8A535X03 Rev. Preliminary-00 Page 13 of 17
