- Page 1 Auto Rewind Hose Reel 16mm x 25m High Flow Hose Instruction Manual 25M High Flow Auto Rewind Hose Reel Installation and Troubleshooting Guide...
- Page 2 Product Code: 1125H Introduction Thank you for purchasing this HOLMAN Auto Rewind Hose Reel. This product uses a 16mm reinforced hose for added strength and durability, and includes a high flow adjustable nozzle. For your information, please read these installation instructions before using the Auto Rewind Hose Reel.
- Page 3 Auto Rewind Hose Reel - Instruction Manual Hose Reel Operating Features Supplied with each hose reel is a strong Lift the hose reel top cover for easy coated wall bracket and hose end plug access to either clean or replace your for convenient storage when not in use.
- Page 4 Auto Rewind Hose Reel - Instruction Manual Auto Rewind Hose Reel Installation The Auto Rewind Hose Reel should be Take the coated mounting bracket and installed nearest to your chosen water place against either a wall or wooden post. source for convenience of use. Check Mark the position of where you would like the tap to reel hose can reach the tap the screws to be placed through the centre...
- Page 5 Auto Rewind Hose Reel - Instruction Manual Place the bracket in position over Take your Auto Rewind Hose Reel, and the four wall plugs and screw each remove the securing pin at the base of hexagonal coach bolt into your wall the mounting tube.
- Page 6 Troubleshooting - Hose Reel Not Retracting Locking Bars Preventing Retraction Locking bars in the WRONG position Locking bars in the CORRECT laying on the hose. They will cause the position, clipped to the outer casing. hose to jam as it extends or retracts. Locking bars in the WRONG position.
- Page 7 Troubleshooting - Hose Reel Not Extending Fully Retracted Hose Not Extending If the hose isn’t extending properly, Slowly pull the hose to move the guide this may be caused by the screws hole away from the inside edge of the securing the guide hole being too tight.
- Page 8 Should you have any questions about this product or its operation please telephone our customer service helpline on 1300 716 188. Holman offer a 2 year replacement warranty from the original date of purchase. To claim warranty the product must be returned with a copy of the original receipt.
