Misting System
Parts Included:
• 20 x Metres of Misting Hose
• 19 x Misting Tees
• 20 x Brass Misting Nozzles
• 3 x Elbow Connector
• 1 x Auto Draining Valve
• 1 x Pipe Cutter
Instruction Manual
Product Code: MK21015
Note: Flush Misting System thoroughly before
attaching misting Nozzles to prevent blockages.
Scan the QR Code on the right to see more information on
the Misting System - including a product guide video.
2014-Misting System Deluxe Instruction Manual V2.indd 1
20
Metre Deluxe Kit
• 30 x Hose Clamps with Masonary Nails
• 3 x Misting Elbow
• 3 x Tee Connector
• 1 x Misting Filter
• 1 x Misting Universal Tap Adaptor
7/08/2014 4:36:09 PM
