Four-Faith F8916-L-G User Manual

F8916-l series ip modem
Hide thumbs Also See for F8916-L-G:
Table of Contents

Advertisement

Quick Links

Download this manual
F8916-L Series
IP MODEM
User Manual
IP MODEM User Manual
The user manual is suitable for the following model:
Document Version
Product Name：F8916-L
F8916-L Series
F8916-L-G
LoRa+GPRS IP MODEM
F8916-L-C
LoRa+CDMA IP MODEM
F8916-L-W
LoRa+WCDMA IP MODEM
F8916-L-V
LoRa+EVDO IP MODEM
F8916-L-TL
LoRa+TDD LTE IP MODEM
F8916-L-FL
LoRa+FDD LTE IP MODEM
F8916-L-L
LoRa+LTE IP MODEM
Xiamen Four-Faith Communication Technology Co., Ltd.
Add： J1-J3, 3rd Floor, No.44,Guanri Road, Software Park, Xiamen, China
Postal Code:361008
Tel：+86 -592-6300320
Fax:+86-592-5912735
http://en.four-faith.com
V1.0.0
Page
Total:39

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F8916-L-G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Four-Faith F8916-L-G

Summary of Contents for Four-Faith F8916-L-G

  • Page 1 F8916-L-V LoRa+EVDO IP MODEM F8916-L-TL LoRa+TDD LTE IP MODEM F8916-L-FL LoRa+FDD LTE IP MODEM F8916-L-L LoRa+LTE IP MODEM Xiamen Four-Faith Communication Technology Co., Ltd. Add： J1-J3, 3rd Floor, No.44,Guanri Road, Software Park, Xiamen, China Postal Code:361008 Tel：+86 -592-6300320 Fax:+86-592-5912735 http://en.four-faith.com...
  • Page 2 F8916-L Series IP MODEM User Manual Files Revised Record Date Version Remark Author 2016-11-1 V1.0.0 Initial version WSP/ZXZ Xiamen Four-Faith Communication Technology Co.,Ltd. Page 2 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com Tel： +86-592-6300320 Fax：+86-592-5912735...

  • Page 3: Copyright Notice

    Xiamen Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
  • Page 4 F8916-L Series IP MODEM User Manual Note: There may be different components and interfaces in different model,please in kind prevail. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 4 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...

  • Page 5: Table Of Contents

    3.3.8.1 Device Manage Center Parameters...............33 3.3.8.2 Manage by SMS....................34 3.3.9 LoRa Setting......................34 3.3.10 Miscellaneous..................... 35 Appendix............................37 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 5 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com Tel： +86-592-6300320 Fax：+86-592-5912735...

  • Page 6: Chapter 1 Brief Introduction Of Product

     Support hardware and software WDT  Support auto recovery mechanism, including online detect, auto redial when offline to make it always online Xiamen Four-Faith Communication Technology Co.,Ltd. Page 6 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...

  • Page 7: Working Principle

     Support APN/VPDN  Support transferring data via LoRa 1.3 Working Principle The principle chart of the IP MODEM is as following: Xiamen Four-Faith Communication Technology Co.,Ltd. Page 7 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...

  • Page 8: Specifications

    F8916-L Series IP MODEM User Manual 1.4 Specifications Cellular Specification ITEM CONTENT F8916-L-G LoRa+GPRS IP MODEM Standard and Band EGSM 900/GSM 1800MHz, GSM 850/900/1800/1900MHz(optional) Compliant to GSM phase 2/2+ GPRS class 10, class 12(optional) Bandwidth 85.6Kbps TX power GSM850/900:<33dBm GSM1800/1900:<30dBm RX sensitivity <-107dBm...
  • Page 9 DC-HSPA+: Download speed 42Mbps, Upload speed 5.76Mbps HSPA+: Download speed 21Mbps, Upload speed 5.76Mbps HSDPA: Download speed 7.2Mbps, HSUPA: Upload speed 5.76Mbps Xiamen Four-Faith Communication Technology Co.,Ltd. Page 9 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...
  • Page 10 2 RS232 port and 1 RS485(orRS422) port, 15KV ESD protection Data bits: 5, 6 ,7, 8 Stop bits: 1, 1.5, 2 Parity: none, even, odd, space, mark Xiamen Four-Faith Communication Technology Co.,Ltd. Page 10 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...
  • Page 11 4G:150~200mA ) Sleep 3mA@12VDC 6mA@5VDC Physical Characteristics Item Content Housing Iron, providing IP30 protection Dimensions 91x58.5x22 mm Xiamen Four-Faith Communication Technology Co.,Ltd. Page 11 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com Tel： +86-592-6300320 Fax：+86-592-5912735...
  • Page 12 Weight 210g Environmental Limits Item Content Operating -35~+75ºC(-31~+167℉) Temperature Storage -40~+85ºC(-40~+185℉) Temperature Operating Humidity 95% (Non-condensing) Xiamen Four-Faith Communication Technology Co.,Ltd. Page 12 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com Tel： +86-592-6300320 Fax：+86-592-5912735...

  • Page 13: Chapter 2 Installation Introduction

    RS485 data cable optional Manual CD Certification card Maintenance card 2.3 Installation and Cable Connection Dimension: (unit: mm) Xiamen Four-Faith Communication Technology Co.,Ltd. Page 13 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com Tel： +86-592-6300320 Fax：+86-592-5912735...
  • Page 14 Number Power input anode Power Ground RS232 RX RS232 TX System Ground RS232 RX Reserved compatible Xiamen Four-Faith Communication Technology Co.,Ltd. Page 14 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com Tel： +86-592-6300320 Fax：+86-592-5912735...
  • Page 15 Cable Color Signal definition RS485(A) Black RS485(B) Power adapter and communication cable connection chart as following: Xiamen Four-Faith Communication Technology Co.,Ltd. Page 15 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com Tel： +86-592-6300320 Fax：+86-592-5912735...

  • Page 16: Power

    IP MODEM has logged on network IP MODEM hasn’t logged on network LoRa LoRa has been identified LoRa is not recognized Xiamen Four-Faith Communication Technology Co.,Ltd. Page 16 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com Tel： +86-592-6300320 Fax：+86-592-5912735...

  • Page 17: Chapter 3 Configuration

    The following describes how to configure IP MODEM with the configure software tool. At the same time, it gives out the corresponding AT command of each configuration item. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 17 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China...

  • Page 18: Ip Modem's Parameters Configuration

    “Output Info” column will display “Port(COM1) Has Opened，Please Re-Power the IP MODEM, Waiting IP MODEM Enter Configure State...” Xiamen Four-Faith Communication Technology Co.,Ltd. Page 18 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...

  • Page 19: Re-Power Ip Modem

    PROT It uses TCP Protocol to send or receive data. In this mode, ID and phone number MUST be set. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 19 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...
  • Page 20 IP MODEM work as a SMS DTU. All data will send to binding phone number via SMS. The SMS from the binding phone number will send to Serial port. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 20 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China...
  • Page 21 If convert HEX data to ASCII data or not Custom protocol：client mode It support TCP and UDP protocol with custom heart and login packet. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 21 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...
  • Page 22 It supports TCP and udp server. Base Protocol TCP or UDP Listen Port Listen port for service Xiamen Four-Faith Communication Technology Co.,Ltd. Page 22 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com Tel： +86-592-6300320 Fax：+86-592-5912735...

  • Page 23: Trigger Mode

    IP Modem. Note：if the trigger phone was set, the sim card in IP Modem Must have “caller ID display” function. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 23 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China...
  • Page 24 Sleep/Wakeup Made the IP Modem sleep or wake up depended on the I/O state Set I/O port to trigger the IP Modem to sleep or wake up Xiamen Four-Faith Communication Technology Co.,Ltd. Page 24 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...
  • Page 25 MIXD the combination of SMSD, CTRL, DATA. IP MODEM will be online when meet one of these three trigger methods. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 25 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...

  • Page 26: Debug Level

    Port 1：debug info send to port 1 Debug Port Port 2：debug info send to port 2 485：debug info send to RS485 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 26 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...

  • Page 27: Data Service Center Settings

    When it detects the main server work fine, it will return back to the main server at once. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 27 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...

  • Page 28: Multi-Center Connection Check

    Data Send Type Poll：send data to the centers order by order. Once data send success, it will stop to send to next other centers. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 28 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...

  • Page 29: Serial Port

    --- 57600 bps 115200 --- 115200 bps Property：Databit, Parity, Stopbit 8N1 --- 8 Databit, No parity, 1 Stopbit Xiamen Four-Faith Communication Technology Co.,Ltd. Page 29 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com Tel： +86-592-6300320 Fax：+86-592-5912735...

  • Page 30: Dial

    DialNo *99***1#、 *99#、 *98*1# GPRS/WCDMA/LTE CDMA/EVDO #777 Network GPRS/WCDMA cmnet、uninet /LTE CDMA/EVDO Empty Network User name/password Xiamen Four-Faith Communication Technology Co.,Ltd. Page 30 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com Tel： +86-592-6300320 Fax：+86-592-5912735...

  • Page 31: Ppp Redial

    3.3.7 Global Parameters 3.3.7.1 PPP Link Check PPP Link Check adopt LCP echo method to check the link status. Once the check Xiamen Four-Faith Communication Technology Co.,Ltd. Page 31 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...

  • Page 32: Icmp Link Check

    >= 3 times 3.3.7.3 Other Parameters SMS Center Your local SMS center number. It should set according to the local operation. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 32 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...

  • Page 33: Data Frame Parameters

    Device ID for manage center. 8 character Dev ID For Manage TCP or UDP Protocol Xiamen Four-Faith Communication Technology Co.,Ltd. Page 33 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com Tel： +86-592-6300320 Fax：+86-592-5912735...

  • Page 34: Manage By Sms

    The ID of the LoRa module to transfer data. The ID range is 0~65535 The physical frequency channel of the module. The Channel Xiamen Four-Faith Communication Technology Co.,Ltd. Page 34 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...

  • Page 35: Miscellaneous

    GPRS and LoRa bi-direction. 3.3.10 Miscellaneous Login Enter configuration state while IP Modem normal work. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 35 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com Tel： +86-592-6300320 Fax：+86-592-5912735...
  • Page 36 CheckCard Query the CSQ of IP Modem QuerySignal Set the system time for IP Modem Clock Xiamen Four-Faith Communication Technology Co.,Ltd. Page 36 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com Tel： +86-592-6300320 Fax：+86-592-5912735...

  • Page 37: Appendix

    2. Input connection name, choose “OK” 3. Choose the correct COM port which connect to IP MODEM, choose “OK” 4. Configure the serial port parameters as following, choose “OK” Xiamen Four-Faith Communication Technology Co.,Ltd. Page 37 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China...
  • Page 38 5. Complete Hyper Terminal operation, It runs as following Re-power IP MODEM, put mouse focus on the Hyper Terminal and press “s” key continuously until IP MODEM enter configure state as following Xiamen Four-Faith Communication Technology Co.,Ltd. Page 38 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China...

  • Page 39: Xiamen Four-Faith Communication Technology Co.,Ltd

    F8916-L Series IP MODEM User Manual 7. IP MODEM has entered configure state, you can configure the parameters through AT command. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 39 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...
