Four-Faith F8916-L Series User Manual

Ip modems
Hide thumbs Also See for F8916-L Series:
Table of Contents

Advertisement

Quick Links

Download this manual
All manuals and user guides at all-guides.com
F8916-L Series
IP MODEM
User Manual
F8916-L Series
IP MODEM User Manual
The user manual is suitable for the following model:
F8916-L-G
F8916-L-C
F8916-L-W
F8916-L-V
F8916-L-TL
F8916-L-FL
F8916-L-L
Document Version
V1.0.0
Product Name：F8916-L
LoRa+GPRS IP MODEM
LoRa+CDMA IP MODEM
LoRa+WCDMA IP MODEM
LoRa+EVDO IP MODEM
LoRa+TDD LTE IP MODEM
LoRa+FDD LTE IP MODEM
LoRa+LTE IP MODEM
Xiamen Four-Faith Communication Technology Co., Ltd.
Add： J1-J3, 3rd Floor, No.44,Guanri Road, Software Park, Xiamen, China
Postal Code:361008
Tel：+86 -592-6300320
Fax:+86-592-5912735
http://en.four-faith.com
Page
Total:39

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F8916-L Series and is the answer not in the manual?

Questions and answers

Related Manuals for Four-Faith F8916-L Series

Summary of Contents for Four-Faith F8916-L Series

  • Page 1 F8916-L-V LoRa+EVDO IP MODEM F8916-L-TL LoRa+TDD LTE IP MODEM F8916-L-FL LoRa+FDD LTE IP MODEM F8916-L-L LoRa+LTE IP MODEM Xiamen Four-Faith Communication Technology Co., Ltd. Add： J1-J3, 3rd Floor, No.44,Guanri Road, Software Park, Xiamen, China Postal Code:361008 Tel：+86 -592-6300320 Fax:+86-592-5912735 http://en.four-faith.com...
  • Page 2 All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual Files Revised Record Date Version Remark Author 2016-11-1 V1.0.0 Initial version WSP/ZXZ Xiamen Four-Faith Communication Technology Co.,Ltd. Page 2 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...
  • Page 3 Xiamen Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
  • Page 4 All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual Note: There may be different components and interfaces in different model,please in kind prevail. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 4 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China http://en.four-faith.com...

  • Page 5: Table Of Contents

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual Contents Contents Chapter 1 Brief Introduction of Product..................6 1.1 General..........................6 1.2 Features and Benefits......................6 1.3 Working Principle.......................7 1.4 Specifications........................8 Chapter 2 Installation Introduction....................13 2.1 General..........................

  • Page 6: Chapter 1 Brief Introduction Of Product

    Chapter 1 Brief Introduction of Product 1.1 General F8916-L series IP MODEM is a kind of cellular terminal device that provides data transfer by public cellular network. At the same time using LoRa wireless transmission technology for short distance data transmission.

  • Page 7: Working Principle

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual  RS232/RS485/RS422 port: 15KV ESD protection  SIM/UIM port: 15KV ESD protection  Power port: reverse-voltage and overvoltage protection  Antenna port: lightning protection(optional) Standard and Convenience ...

  • Page 8: Specifications

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual 1.4 Specifications Cellular Specification ITEM CONTENT F8916-L-G LoRa+GPRS IP MODEM Standard and Band EGSM 900/GSM 1800MHz, GSM 850/900/1800/1900MHz(optional) Compliant to GSM phase 2/2+ GPRS class 10, class 12(optional) Bandwidth 85.6Kbps...
  • Page 9 All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual GPRS/EDGE CLASS 12 Bandwidth DC-HSPA+: Download speed 42Mbps, Upload speed 5.76Mbps HSPA+: Download speed 21Mbps, Upload speed 5.76Mbps HSDPA: Download speed 7.2Mbps, HSUPA: Upload speed 5.76Mbps UMTS: 384Kbps TX power <24dBm...
  • Page 10 All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual UMTS: 384Kbps TX power <23dBm RX sensitivity <-97dBm F8916-L-L LoRa+LTE IP MODEM Standard and Band LTE FDD,LTE TDD,EVDO,WCDMA,TD-SCDMA,CDMA1X,GPRS/EDGE Bandwidth LTE FDD: Download speed 100Mbps, Upload speed 50Mbps LTE TDD: Download speed 61Mbps, Upload speed 18Mbps DC-HSPA+: Download speed 42Mbps, Upload speed 5.76Mbps...
  • Page 11 All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual Baud rate: 110~230400 bps Indicator “Power”, “ACT”, "Online”, "LoRa” Antenna Cellular :Standard SMA female interface, 50 ohm, lighting protection(optional) LoRa : Standard SMA female interface, 50 ohm, lighting...
  • Page 12 All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual Weight 210g Environmental Limits Item Content Operating -35~+75ºC(-31~+167℉) Temperature Storage -40~+85ºC(-40~+185℉) Temperature Operating Humidity 95% (Non-condensing) Xiamen Four-Faith Communication Technology Co.,Ltd. Page 12 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China...

  • Page 13: Chapter 2 Installation Introduction

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual Chapter 2 Installation Introduction 2.1 General The IP MODEM must be installed correctly to make it work properly. Warning: Forbid to install the IP MODEM when powered! 2.2 Encasement List...
  • Page 14 All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual Ф3 Ф5 58.5 Installation of SIM/UIM card: Firstly power off the IP MODEM, and press the out button of the SIM/UIM card outlet with a needle object. Then the SIM/UIM card sheath will flick out at once. Put SIM/UIM card into the card sheath (Pay attention to put the side which has metal point outside), and insert card sheath back to the SIM/UIM card outlet.
  • Page 15 All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual RS232 RX (TTL logic level) RS232 TX Reserved compatible RS232 TX (TTL logic level) RS485 anode Reserved compatible ADC RS485 cathode Reserved compatible ADC GPIO Reserved compatible pulse wave...

  • Page 16: Power

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual Connect via RS232 Connect via RS485 + Anode + Anode - Cathode - Cathode ADC1 ADC1 User device F8916-L User Device F8916-L (DB9M) 2.4 Power The power range of the IP MODEM is DC 5~36V.

  • Page 17: Chapter 3 Configuration

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual Chapter 3 Configuration 3.1 Configuration Connection Before configuration, It’s necessary to connect the IP MODEM with the configure PC by the shipped RS232 or RS232-485 conversion cable as following.

  • Page 18: Ip Modem's Parameters Configuration

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual 3.3 IP Modem’s Parameters Configuration 3.3.1 Run the Configure Tools The “Serial” area shows the current serial port settings. To configure IP MODEM, please choose the correct serial port which connects to IP MODEM, and the baud-rate is 115200 with no parity, then open the serial port.

  • Page 19: Re-Power Ip Modem

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual 3.3.2 Re-Power IP Modem After Re-power IP MODEM, The configure tool will make it enter configure state. At the same time, the software will load current settings from IP MODEM and displays on the right configure columns.
  • Page 20 All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual DeviceID ID number for the device. 8 characters PhoneNo. Phone number Transfer Meaning This item is only valid when the WorkMode is PROT. If this item is set to 0, IP MODEM will transfer meaning to 0xfd and 0xfe.
  • Page 21 All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual Pone No 1st Group Bind phone number. Max phone number is 5 for one group Pone No 2nd Group Pone No 3rd Group Pone No 4th Group...
  • Page 22 All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual Base Protocol TCP or UDP DeviceMode Client Mode: the IP Modem work as a client. Login&Heartbeat Enable: custom login and heart packet Disable: no login and heart packet. The flowing items can be ignored.

  • Page 23: Trigger Mode

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual 3.3.3.2 Trigger mode Normally, IP MODEM always keeps online and always be ready for data transmission. But in some circumstances, it’s important to reduce wireless data flow. To realize this function, the software can makes IP MODEM into sleep state in idle time.
  • Page 24 All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual CALL Phone No. Trigger phone number DATA send special serial data to make IP MODEM online Data Trigger On If it was empty, any data form serial can trigger the IP Modem.
  • Page 25 All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual I/O：online or offline Made the IP Modem online or offline via I/O level. If the I/O was in high level or suspend, the IP Modem was offline. Otherwise, It would trigger the IP Modem online.

  • Page 26: Debug Level

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual CALL Phone No. Any phone number call can wake up IP Modem, if the trigger number is empty. Otherwise only the trigger phone number call can trigger the IP Modem.

  • Page 27: Data Service Center Settings

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual 3.3.4 Data Service Center Settings Settings on this page are the parameters related to Data Service Center (DSC). 3.3.4.1 Data Service Center IP MODEM support two Data Service Center methods to transmit data.

  • Page 28: Multi-Center Connection Check

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual If the Data Center Number is 0,there is no DSC working. If the Data Center Number is 1, IP MODEM work in Main and Backup DSC method.

  • Page 29: Serial Port

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual 3.3.5 Serial port IP MODEM support three individual serial ports, Port1, Port2 and RS485. All the three ports can enter configuration state. The default parameters of the port with baudrate 115200, data property 8N1 The data from the three port can bind to Data center.

  • Page 30: Dial

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual 8E1 --- 8 Databit, Even parity, 1 Stopbit 8O1 --- 8 Databit, Odd parity, 1 Stopbit Bind： Center1: the data from the port send to center 1...

  • Page 31: Ppp Redial

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual GPRS/WCDMA empty Username/passwor /LTE CDMA/EVDO card/card PPP Auth AUTO,PAP and CHAP QueryNetMode Search the network mode for the 4G network 3.3.6.2 PPP Redial Re-dial Interval(s) The interval between ppp dial in second...

  • Page 32: Icmp Link Check

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual failure’s times meet the max times. The IP Modem will re-dial. Lcp Echo Enable or Disable Echo Interval(s) The interval should not be too small. 60 is recommended. (in...

  • Page 33: Data Frame Parameters

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual Heartbeat Int.(s) Time interval sent heartbeat packet. (in second) 3.3.7.4 Data Frame Parameters Bytes Interval(MS) The time interval used to determine whether the serial data frame transmission has completed, IP MODEM will send the serial data to the center when two bytes transmit time interval larger than this item value.(in milliseconds)

  • Page 34: Manage By Sms

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual manage center server address Service Address manage center server port Port 3.3.8.2 Manage by SMS Configure the IP Modem by SMS SMS Configure Enable or Disable The password for SMS Configure...

  • Page 35: Miscellaneous

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual band-width of LoRa is 410MHz to 441MHz with 1000Hz as a channel. There are 32 channesl can be selected. The bit error rate is different from each channel. A suitable channel should be selected according to the application.
  • Page 36 All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual Send parameters to IP Modem WriteParam Read All parameters of IP Modem ReadParam Read log information of IP Modem ReadLog Factory the IP Modem’s parameters Factory Query the version of IP Modem...

  • Page 37: Appendix

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual Appendix The following steps describe how to make IP MODEM enter configure state with the Windows XP Hyper Terminal. 1. Press “Start””Programs””Accessories””Communications””Hyper Terminal” 2. Input connection name, choose “OK”...
  • Page 38 All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual Bits per second: 115200 Data bits: 8 Parity: None Stop bits: 1 Flow control: None 5. Complete Hyper Terminal operation, It runs as following Re-power IP MODEM, put mouse focus on the Hyper Terminal and press “s” key continuously until IP MODEM enter configure state as following Xiamen Four-Faith Communication Technology Co.,Ltd.

  • Page 39: Xiamen Four-Faith Communication Technology Co.,Ltd

    All manuals and user guides at all-guides.com F8916-L Series IP MODEM User Manual 7. IP MODEM has entered configure state, you can configure the parameters through AT command. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 39 of 39 Add： J1-J3, 3 Floor, No.44, Guanri Road, Software Park, Xiamen .361008.China...
