Four-Faith F1003 User Manual

F1x03 series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
F1X03 Series
User Manual
F1X03 Series User Manual
The user manual is suitable for the following model:
Documentation No.
Product Name：
Model
Product Type
F1003
GSM MODEM
F1103
GPRS MODEM
F1203
CDMA MODEM
F1303
EDGE MODEM
F1403
WCDMA MODEM
F1503
TD-SCDMA MODEM
F1603
EVDO MODEM
Xiamen Four-Faith Communication Technology Co., Ltd.
Add：J1-J3,3rd Floor,No.44,GuanRi Road,SoftWare
Park,XiaMen,China
Tel：+86 592-6300326 ，6300325，6300324
Fax:+86 592-5912735
http://www.fourfaith.com
Product Version
Zip Code:361008
Page
Total:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F1003 and is the answer not in the manual?

Questions and answers

Related Manuals for Four-Faith F1003

Summary of Contents for Four-Faith F1003

  • Page 1 Product Type F1003 GSM MODEM F1103 GPRS MODEM F1203 CDMA MODEM F1303 EDGE MODEM F1403 WCDMA MODEM F1503 TD-SCDMA MODEM F1603 EVDO MODEM Xiamen Four-Faith Communication Technology Co., Ltd. Add：J1-J3,3rd Floor,No.44,GuanRi Road,SoftWare Park,XiaMen,China Zip Code:361008 Tel：+86 592-6300326 ，6300325，6300324 Fax:+86 592-5912735 http://www.fourfaith.com...
  • Page 2 User Manual Files Revised Record Date Version Remark Author Xiamen Four-Faith Communication Technology Co.,Ltd. Page 2 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 3: Copyright Notice

    Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc., but non-commercial purpose, downloaded or printed by individual (all files shall be not revised, and the copyright and other proprietorship notice shall be reserved) are welcome.
  • Page 4 User Manual Xiamen Four-Faith Communication Technology Co.,Ltd. Page 4 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 5: Table Of Contents

    Chapter 3 Dial-Up Settings ......................13 3.1 MODEM Connection ......................13 3.2 Dial-Up Settings ........................ 13 Chapter 4 SMS Test ........................29 Chapter 5 Appendix ........................32 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 5 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...

  • Page 6: Chapter 1 Brief Introduction Of Product

     Provide dial-up software that can make it always online  Provide SMS tool software  Support standard AT command High-performance  Support SMS  Support dial-up（Except F1003）  CSD function(F1003/F1103) Xiamen Four-Faith Communication Technology Co.,Ltd. Page 6 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...

  • Page 7: Working Principle

    User Manual  Support APN/VPDN（Except F1003） 1.3 Working Principle The principle chart of the MODEM is as following: Cellualr Module User interface RS232 serial Power Indicator lights Interface 1.4 Specifications Cellular Specification Standard and Band Bandwidth TX power sensitivity F1003 GSM MODEM EGSM900/GSM1800MHz, 14.4Kbps CSD...
  • Page 8 Standard 3V/1.8V user card interface, 15KV ESD protection Power Standard 3-PIN power jack, reverse-voltage and overvoltage protection Power Input Item Content Xiamen Four-Faith Communication Technology Co.,Ltd. Page 8 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
  • Page 9 Operating -25~+65º C（-13~+149℉） Temperature Extended -30~+75º C（-22~+167℉） Operating Temperature Storage -40~+85º C（-40~+185℉） Temperature Operating 95% ( Non-condensing) Humidity Xiamen Four-Faith Communication Technology Co.,Ltd. Page 9 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 10: Chapter 2 Installation Introduction

    Certification card Maintenance card 2.3 Installation and Cable Connection : (unit: mm) Dimension Ф 3 Ф 5 58.5 Xiamen Four-Faith Communication Technology Co.,Ltd. Page 10 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 11: Power

    4W. We recommend user to use the standard DC 12V/0.5A power adaptor. 2.5 Indicator Lights Introduction The MODEM provides three indicator lights: “Power”, “ACT”, “Online”. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 11 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 12 BLINK Data is communicating No data Online MODEM has logged on network BLINK MODEM hasn’t logged on network Xiamen Four-Faith Communication Technology Co.,Ltd. Page 12 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 13: Chapter 3 Dial-Up Settings

    Connect Modem and PC with the shipped RS-232 cable as following: 3.2 Dial-Up Settings 1. Press “start”  “Settings”  “Control Panel”, Double click “Phone and Modem Options” 2. Choose “Modems”, Press “Add” button Xiamen Four-Faith Communication Technology Co.,Ltd. Page 13 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 14 3. Choose “Don’t detect my modem;I will select it from a list”, and click “Next” 4. Manufacture choose ”Standard Modem Types”, Models choose “Standard 33600 bps Modem”, click “Next” button Xiamen Four-Faith Communication Technology Co.,Ltd. Page 14 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 15 User Manual 5. “Selected ports” choose the actual COM port which connects to Modem, click “Next” button. 6. click “Finish” button, return back to “Modems” page Xiamen Four-Faith Communication Technology Co.,Ltd. Page 15 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 16 User Manual 7. Choose the modem you have just installed, click “properties“ button to configure the modem driver Xiamen Four-Faith Communication Technology Co.,Ltd. Page 16 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
  • Page 17 Initialization commands: AT+CGDCONT=1,”IP”,”CMNET” , CMNET is the Access Point Name(APN) of China, please replace it with your own APN name, click “Change Default Preferences” button Xiamen Four-Faith Communication Technology Co.,Ltd. Page 17 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
  • Page 18 AT+CGDCONT=1,"IP","CMNET" F1403 AT+CGDCONT=1,"IP","3GNET" F1503 AT+CGDCONT=1,"IP","CMNET" F1603 null 10. “Port Speed” choose 115200，”Flow control” choose None, click “OK” button. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 18 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
  • Page 19 User Manual 11. On the “Advanced” page, click “OK” button return to “Phone and Modems” page, click “OK” button to finish the Modem driver installation Xiamen Four-Faith Communication Technology Co.,Ltd. Page 19 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
  • Page 20 12. Finish installing Modem driver, It’s necessary to install the Dial-Up connection. Open “Control Panel”, double click “Network connections” 13．Click “Create a new connection” to start creating a new Dial-Up connection. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 20 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 21 User Manual 14．Click “Next” button 15．Choose “Connect to the Internet”, click “Next” button Xiamen Four-Faith Communication Technology Co.,Ltd. Page 21 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
  • Page 22 User Manual 16．Choose “Set up my connection manually”, click “Next” 17．Choose “Connect using a dial-up modem”, click “Next” Xiamen Four-Faith Communication Technology Co.,Ltd. Page 22 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
  • Page 23 User Manual 18．Choose the Modem driver installed just now, click “Next” button 19．Input the ISP Name , click “Next” button Xiamen Four-Faith Communication Technology Co.,Ltd. Page 23 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324...
  • Page 24 *99# F1503 *98*1# F1603 #777 21．Input the username and password. In china they are both null. Click “Next”. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 24 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
  • Page 25 22．Choose “Add a shortcut to this connection to my desktop”, click “Finish” button. 23．Double click the Dial-Up shortcut on your desktop to run Dial-Up program. 24．Click the “Properties” button of the Dial-Up program Xiamen Four-Faith Communication Technology Co.,Ltd. Page 25 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 26 User Manual 25．Choose the Modem driver installed before, Click “Configure” button 26．Set “Maximum Speed [bps]” as 115200, set Hardware features as following, click “OK” button Xiamen Four-Faith Communication Technology Co.,Ltd. Page 26 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel：...
  • Page 27 User Manual 27．Click “OK” button to finish Dial-Up program configuration 28．Click “Dial” button to start dial Xiamen Four-Faith Communication Technology Co.,Ltd. Page 27 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...
  • Page 28 User Manual 29．When dial success, There is a connection icon on the right of your taskbar. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 28 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 29: Chapter 4 Sms Test

    4． The tool will initiate Modem after clicking the “Start” button, If initiate success, the log column will show “Start Success”, It’s now ready for sending and receiving SMS. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 29 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 30 5． Input the phone to receive this test SMS, click “Send” button 6． The result state will display in the Log column 7． When received SMS, It will display in the receive column Xiamen Four-Faith Communication Technology Co.,Ltd. Page 30 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
  • Page 31 User Manual 8．Complete SMS test. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 31 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com Tel： +86 592-6300326 6300325 6300324 Fax：+86 592-5912735...

  • Page 32: Chapter 5 Appendix

    2. Input connection name, choose “OK” 3. Choose the correct COM port which connects to modem, choose “OK” 4. Configure the serial port parameters as following, choose “OK” Xiamen Four-Faith Communication Technology Co.,Ltd. Page 32 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China http：//www.fourfaith.com...
  • Page 33 Flow control: None 5. Complete Hyper Terminal operation, It runs as following 6. Type “AT” in the blank of Hyper Terminal and press “Enter”, the modem will return “ok”. Xiamen Four-Faith Communication Technology Co.,Ltd. Page 33 of 33 Add： J1-J3,3 Floor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China...
