- Page 1 Clamp Meter Users Manual...
- Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY This Fluke product will be free from defects in material and workmanship for two years from the date of purchase. This warranty does not cover fuses, disposable batteries, or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
-
Page 3: Table Of Contents
Table of Contents Title Page Introduction ......................... 1 Contact Fluke ......................2 Safety Information ...................... 3 The Meter ........................11 Specifications ......................17 Electrical Specifications ..................17 Mechanical Specifications ..................18 Environmental Specifications ................. 19 Safety Specifications ....................20... - Page 4 Users Manual...
-
Page 5: Introduction
Introduction Warning Read "Safety Information" before you use the Meter. The Fluke 362 is a hand-held, battery-operated clamp meter (the Meter) that measures: • ac and dc current and voltage • resistance • continuity The Meter ships with: • TL75 test leads •... -
Page 6: Safety Information
Clamp Meter Safety Information Safety Information A Warning identifies conditions and actions that pose hazard(s) to the user. A Caution identifies conditions and procedures that could cause Meter damage, equipment under test damage, or permanent loss of data. Symbols used on the Meter and in this manual are explained in Table 1. Warning To prevent possible electrical shock or personal injury, follow these guidelines: •... - Page 7 When batteries are changed, make sure the calibration seal in the battery compartment is not damaged. If damaged, the Meter may not be safe to use. Return the Meter to Fluke for replacement of the seal. • When measuring, keep fingers behind the Tactile Barrier. See "The Meter" .
- Page 8 Clamp Meter Safety Information • To avoid false readings that can lead to electrical shock and injury, replace the batteries as soon as the low battery indicator () appears. • When servicing the Meter, use only specified replacement parts. • Have the Meter serviced only by qualified service personnel.
- Page 9 Users Manual • Use extreme caution when working around bare conductors or bus bars. Contact with the conductor could result in electric shock. • Adhere to local and national safety codes. Individual protective equipment must be used to prevent shock and arc blast injury where hazardous live conductors are exposed.
- Page 10 Clamp Meter Safety Information • Measure a known voltage first to make sure that the Product operates correctly. • Only use probes, test leads, and accessories that have the same measurement category, voltage, and amperage ratings as the Product. • Use Product-approved measurement category (CAT), voltage, and amperage rated accessories (probes, test leads, and adapters) for all measurements.
- Page 11 Users Manual Table 1. Symbols Symbol Meaning Symbol Meaning AC (Alternating Current) Earth ground DC (Direct Current) Double insulated Conforms to European Union Hazardous voltage directives. Conforms to relevant North American Risk of Danger. Important ...
- Page 12 Clamp Meter Safety Information Table 1. Symbols (cont.) Symbol Meaning Symbol Meaning IEC Measurement Category III Measurement Category II is CAT III equipment has protection applicable to test and measuring against transients in equipment in circuits connected directly to CAT II CAT III fixed-equipment installations, such as utilization points (socket outlets...
- Page 13 WEEE Directive Annex I, this the building’s low-voltage MAINS product is classed as category 9 installation. "Monitoring and Control Instrumentation" product. Do not dispose of this product as unsorted municipal waste. Go to Fluke’s website for recycling information.
-
Page 14: The Meter
Clamp Meter The Meter The Meter Clamp Meter fig01.eps... - Page 15 Users Manual Auto Power Off Display Hold AC DC AC DC fig02_3.eps...
- Page 16 Clamp Meter The Meter Fig04_05.eps...
- Page 17 Users Manual fig06_07.eps...
- Page 18 Clamp Meter The Meter Fig08_09.eps...
- Page 19 Users Manual Fig10.eps...
-
Page 20: Specifications
Clamp Meter Specifications Specifications Electrical Specifications AC Current Range ............. 200.0 A Resolution ..........0.1 A Accuracy ..........2 % ±5 digit (45 Hz-65 Hz) 2.5 % ±5 digits (65 Hz-400 Hz) DC Current Range ............. 200.0 A Resolution ..........0.1 A Accuracy .......... -
Page 21: Mechanical Specifications
Users Manual DC Voltage Range ............. 600.0 V Resolution ..........0.1 V Accuracy ..........1 % ±5 digits Resistance Range ............. 300 Ω/ 3000 Ω Resolution ..........0.1 Ω/1 Ω Accuracy ..........1 % ±5 digits Continuity Beeper on Threshold ......≤ 70 Ω Mechanical Specifications Size (L x W x H) ........ -
Page 22: Environmental Specifications
Clamp Meter Specifications Environmental Specifications Operating Temperature ......0 °C to +40 °C Storage Temperature ......-30 °C to +60 °C, 100 hours under -40 °C Operating Humidity ......... Non condensing (< 10 °C) ≤ 90 % RH (at 10 °C to 30 °C) ≤... -
Page 23: Safety Specifications
Users Manual Electromagnetic Environment ....IEC/EN 61326-1 (portable) Temperature Coefficients......Add 0.1 x specified accuracy for each degree C above 28 °C or below 18 °C Safety Specifications Safety Compliance ........IEC/EN 61010-1 IEC/EN 61010-2-032 Batteries ..........2 AAA...
