Using your INTU Mini Kit
temperature range is 100-315°C
or 200-600°F and can be adjusted
in increments of 5°C and 10°F. To
adjust the wattage level whilst in
TCR mode, hold the up adjustment
button and the mode button
simultaneously to increase the
wattage, conversely, hold the down
adjustment button and the mode
button to decrease the wattage.
Configuring TCR Mode:
To set the temperature coefficient
of resistance to match a particular
TW_Intu_Mini_Kit_Compliant_Manual.indd 11
coil, when the device is powered
off simultaneously hold the power
button and the up adjustment button
to enter the TCR configuration
menu. Hold the Power Button for 1-2
seconds to select which to configure
from M1, M2 and M3 – this feature
allows the TCR values for 3 materials
to be stored to the device. Use the
up and down adjustment buttons to
increase or decrease the value to
your preference, leave the device for
5 seconds to confirm the selection.
