Summary of Contents for Totally Wicked Totally Wicked Odyssey
- Page 1 U S E R MA N UA L...
- Page 2 Thank you for purchasing the Odyssey™ Thank you for purchasing your Totally Wicked Odyssey™. The product has been We hope you believe we have achieved our design aim: both designed and manufactured in the United Kingdom, to exacting standards and ‘Something you want to keep forever for the price of something...
-
Page 3: Table Of Contents
Contents Parts description Parts description Your Odyssey™ kit comes with all you will need (except for some e-liquid, which we Filling the tank with e-liquid 18/19 will let you choose!) to get your Odyssey™ vaping experience underway. Please Kit contents Operation take a moment to check your kit contents against the list provided below. -
Page 4: Kit Contents
The following is a step by step guide to assembling and using your product for the 1 x Decorative plinth. first time. We recognise that many Odyssey™ owners will be experienced electronic 1 x Stainless steel tank (3.48ml capacity). cigarette users. However, we believe that following the steps detailed in this section 1 x Mouthpiece/drip-tip. - Page 5 Battery charging • A fully discharged battery may take several hours to charge fully. • If the battery is removed before it is fully charged it will still power the device UK / EU Charging instructions but the operating time will be reduced. •...
- Page 6 Battery charging • A fully discharged battery may take several hours to charge fully. • If the battery is removed before it is fully charged it will still power the device USA Charging instructions but the operating time will be reduced. •...
-
Page 7: Introducing The Odyssey Tank
Holding the cartomizer to the Odyssey™. You will notice that the cartomizer has two holes, each hole is at an angle as illustrated (FIG 1), drip e-liquid onto the inside wall of the cartomizer 1mm in diameter and are placed 180 degrees apart. -
Page 8: Assembly And Operation Of Your Odyssey
• Take the plinth (4) and screw the plinth, narrow section toward the battery body, unlock and allow for power application. Avoid depressing the button whilst attempting until the plinth is fully seated and hand tight. to lock the Odyssey™, as it will only lock in the ‘out’ rather than the ‘in’ position. - Page 9 Fitting the cartomizer into the fluid tank and preparing to fill Carefully insert the cartomizer into the tank. The cartomizer should be inserted squarely into the tank, using a gentle twisting action to push the cartomizer smoothly through the O-rings. Take care not to insert the cartomizer off-square as this can lead to O-ring damage.
- Page 10 The Odyssey Tank™ is now ready for first use. e-liquid into the filler. If the filler air-locks...
-
Page 11: Operation
Operation Compatibility With the Odyssey™ now fully assembled and the operation of the locking The Odyssey™ battery holder has been designed to accommodate the widest and power switch understood, you are ready to go. Holding the device in range of atomizers. As is illustrated below, the device can be used with all your either hand, we recommend holding the device in the manner shown below. -
Page 12: Avoiding Flooding And
Once you have the experience Battery life: to know when your Odyssey Tank™ seems to be about to flood, clicking the tank up Average users should achieve between 4 and 6 hours of operation before a recharge is into this “anti-flooding”... -
Page 13: Care And Maintenance
You can replace the damaged ‘O’ rings yourself, or for Cleaning and general maintenance: a nominal fee you can return the tank to us for ‘O’ ring replacement, full details are Keep the contacts and threads between the cartomizer/atomizer and the Odyssey™ available on our website. body clean. -
Page 14: Important Safety Information
Please read this manual in full to get the most out of the Odyssey™ The Odyssey™ is strictly for the use of person or persons who are already smokers This manual contains important safety information, so read everything in full before of conventional tobacco products or electronic cigarettes. -
Page 15: Troubleshooting
O-ring in the lock mechanism is with Loctite™ 243 thread- too cold. Holding the end of the locking adhesive. Odyssey in your hand gener- Battery life. Decreased vaping time or Replace battery. ally provides enough warmth for early performance drop-off normal function to return. - Page 16 Battery: 14500 3.7v 900mAh Lithium ion protected battery, 14mm(D) x 50mm (L); Weight 21g. Tank: 18.5mm(D) x 43.5mm(L), weight 21g. Odyssey™ Body: 17.5mm(D) x 103.5mm(L), weight 68g. Plinth: 17mm(D) x 10.5mm(L), weight 6g. Mouthpiece/drip-tip: 9.5mm(D) x 25mm(L), weight 8g. Filling device: 14.5mm(D) x 31mm(L), weight 14g.
- Page 17 Odyssey™. Matt Rogers’ contribution must be recognised here. led to the development of the Odyssey™. In conceiving the design, it was recognised At Totally Wicked, we hold both Matt and Ted Rogers as friends of the company, and...
- Page 18 Thank You. Therein was spawned the Odyssey™ design. Along the way, we have built a very strong relationship with the two partners that have done so much to deliver the concept to production. Firstly, University of Central Lancashire (UCLAN), or more specifically, Liam Humberstone, who is a senior lecturer in the University’s...
- Page 19 Manufactured in the UK for Pillbox38 UK Ltd, Stancliffe Street, Blackburn, Lancashire, BB2 2QR. UK: Tel 0845 602 9661 www.totallywicked-eliquid.co.uk USA: Tel 1(888) 761-9425 www.totallywicked-eliquid.com GERMANY: Tel 01803 942533 www.totallywicked-eliquid.de...
