- Page 1 KA980100TX “CELTIC” BAKERS RACK For assistance with assembly contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com...
- Page 2 “CELTIC” BAKERS RACK Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. crews shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 3 Assembly Tool Required No.2 Phillips Screwdriver (Not Included) “CELTIC” BAKERS RACK Assembly Instructions Assembly Instructions: Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated on the front page. Please insert Upper back panel(A) into lower back panel(B) and then Insert 2pcs Short bolt (3) through holes on back Frame(A) to attach...
- Page 4 Figure 2 “CELTIC” BAKERS RACK Assembly Instructions Insert 4pcs long bolt (1) through holes on lower side panel (C) to attach the 2pcs lower shelf (E), and insert 4pcs Middle bolt (2) through holes on lower back Frame (B) to attach the 2pcs lower shelf (E) Insert 2pcs long bolt (1) through holes on lower side panel (C) to...
- Page 5 Figure 3...
- Page 6 (within 9 months), we are under no obligation to provide parts or replacement merchandise. Parts will not be available for items arriving fully assembled. Parts will be sent if available from SEI...
