- Page 1 KA1112 HONEY KITCHEN TABLE&STOOLS RICH BROWN OAK For assistance with assembly contact: Southern Enterprises, Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com wwww.seidal.com...
- Page 2 HONEY KITCHEN TABLE&STOOLS RICH BROWN OAK Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 3 Quantity Quantity of 4 of 2 DRAWER BACK Quantity Quantity of 2 of 2 DRAWER BOTTOM DRAWER FRONT Quantity Quantity of 4 of 2 DRAWER SIDE SEAT PANEL Quantity Quantity of 4 of 4 LEG FRAME LOWER CROSS BAR Quantity Quantity of 4 of 4...
- Page 4 Quantity Quantity of 36 Of 16 LARGE WOOD DOWEL BIG WOOD SCREW Quantity Quantity Of 2 of 2 LONG SCREW KNOB Quantity Quantity Of 16 of 16 ￠1/4*2-1/2 ” CAMLOCK BIG BOLT Quantity of 4 Quantity of 18 ￠1/4*1” ￠1/4*1-1/4” SMALL BOLT MIDDLE BOLT Quantity of 1...
- Page 5 HONEY KITCHEN TABLE&STOOLS RICH BROWN OAK Assembly Instructions Connect the FRONT/BACK APRON (E/F) with the LEFT/RIGHT FACING SIDE PANEL (B/C) using the SMALL WOOD DOWELS (14),MIDDLE BOLTS(8) and WASHERS(13). Tighten them with the ALLEN WRENCH (9). Figure 1 Connect the previously assembled portion with the TOP PANEL (A) using LARGE WOOD DOWELS (1), MIDDLE BOLTS (8) and WASHERS (13).
- Page 6 HONEY KITCHEN TABLE&STOOLS RICH BROWN OAK Assembly Instructions Insert the CROSS BAR (H) into the holes in both the SIDE BARS(G) .Use the SMALL BOLTS(7) and WASHERS (13) to attach the 2 SIDE BARS (G) to the LEFT FACING SIDE PANEL(B) from the back of the LEFT FACING SIDE PANEL(B) .
- Page 7 HONEY KITCHEN TABLE&STOOLS RICH BROWN OAK Assembly Instructions Attach the 2pcs DRAWER STOPPER (12) to the pre-drilled hole on the FRONT APRON (E) by screwing the 2pcs MIDDLE WOOD SCREW (11). Figure 5 Assemble the drawer by using the BIG WOOD SCREWS (2).Attach the 2pcs KNOB (4) to the DRAWER FRONTS (L) by using 2pcs LONG SCREW (3).
- Page 8 HONEY KITCHEN TABLE&STOOLS RICH BROWN OAK Assembly Instructions LOWER/UPPER/MIDDLE Connect CROSS BARS (P/Q/R) with the LEG FRAMES (O) using the LARGE WOOD DOWELS (1), CAME BOLTS (6) and CAM LOCKS (5). Cover the holes on the legs with WOOD PLUGS (10). , Figure 7 Put the SEAT PANEL (N) upside down on the floor,...
