  • Page 1 User Manual Model 430 Compact Ozone Analyzer © TELEDYNE API (TAPI) 9970 CARROLL CANYON ROAD SAN DIEGO, CA 92131-1106 Toll-free Phone: 800-324-5190 Phone: +1 858-657-9800 Fax: +1 858-657-9816 Email: api-sales@teledyne.com Website: http://www.teledyne-api.com/ Copyright 2015-2016 08311C DCN7342 Teledyne API 02 September 2016...
  • Page 3 Teledyne API – Model 430 Compact Ozone Analyzer OTICE OF OPYRIGHT © 2015-2016 Teledyne API. All rights reserved. RADEMARKS All trademarks, registered trademarks, brand names or product names appearing in this document are the property of their respective owners and are used herein for identification purposes only.

  • Page 4: Safety Messages

    GENERAL SAFETY HAZARD This instrument should only be used for the purpose and in the manner described in this manual. If you use the 430 in a manner other than that for which it was intended, unpredictable behavior could ensue with possible hazardous consequences.
  • Page 5 Teledyne API – Model 430 Compact Ozone Analyzer CONSIGNES DE SÉCURITÉ Des consignes de sécurité importantes sont fournies tout au long du présent manuel dans le but d’éviter des blessures corporelles ou d’endommager les instruments. Veuillez lire attentivement ces consignes. Chaque consigne de sécurité...

  • Page 6: Warranty

    PRODUCT RETURN All units or components returned to Teledyne API should be properly packed for handling and returned freight prepaid to the nearest designated Service Center. After the repair, the equipment will be returned, freight prepaid.

  • Page 7: About This Manual

    Teledyne API – Model 430 Compact Ozone Analyzer ABOUT THIS MANUAL Note We recommend that this manual be read in its entirety before any attempt is made to operate the instrument. ONVENTIONS In addition to the safety symbols as presented in the Important Safety Information page, this manual provides special notices related to the safety and effective use of the analyzer and other pertinent information.
  • Page 8 Teledyne API – Model 430 Compact Ozone Analyzer This page intentionally left blank. 08311C DCN7342...

  • Page 9: Table Of Contents

    Teledyne API – Model 430 Compact Ozone Analyzer Table of Contents TABLE OF CONTENTS Safety Messages ..............................ii Warranty ................................iv About This Manual ............................v 1. INTRODUCTION, SPECIFICATIONS, APPROVALS ........ 9 1.1. Overview ............................... 9 1.2. Specifications ............................9 1.3. EPA Designation ..........................10 1.4.
  • Page 10 Table of Contents Teledyne API – Model 430 Compact Ozone Analyzer Figure 5-1. Model 430 Pneumatic Diagram ......................26 Figure 5-2. Model 430 Electronic Diagram .......................27 TABLES Table 1-1: Model 430 Specifications .......................... 9 Table 2-1. Analog Output Pin Assignments ......................14 Table 2-2.

  • Page 11: Introduction, Specifications, Approvals

    1.1. OVERVIEW The Model 430 is a compact, portable ozone analyzer that can be used for regulatory, research, or educational monitoring in routine, remote, and mobile air applications. Because of its low power consumption, it can be run from various DC power sources, such as batteries or solar panels, and can use car adapters.

  • Page 12: Epa Designation

    U.S. Federal Register – http://www3.epa.gov/ttn/amtic/criteria.html. 1.4. APPROVALS AND CERTIFICATIONS The Teledyne API Model 430 was designed, tested and certified for Safety and Electromagnetic Compatibility (EMC). This section presents the compliance statements for those requirements and directives. For additional certifications, please contact Technical...

  • Page 13: Instrument Layout

    Teledyne API – Model 430 Compact Ozone Analyzer Introduction, Specifications, Approvals 1.5. INSTRUMENT LAYOUT 1.5.1. FRONT PANEL Figure 1-1. Model 430 Front Panel 1.5.2. REAR PANEL Figure 1-2. Model 430 Rear Panel 1.6. OPTIONAL RECHARGEABLE EXTERNAL BATTERY The external battery option, rated for 14 hours of continuous use, is available for remote operation.

  • Page 14: Getting Started

    Getting Started Teledyne API – Model 430 Compact Ozone Analyzer GETTING STARTED This section addresses the procedures for unpacking, inspecting, setting up the instrument, and conducting an initial calibration check. 2.1. UNPACKING AND INSPECTING THE INSTRUMENT COULD DAMAGE INSTRUMENT AND VOID WARRANTY...

  • Page 15: Pneumatic Connections

    3 meters for all I/O connections, which include Power, Analog In, Analog Out, RS-232, and RS-485. The Model 430 rear panel (Figure 1-2) has connectors for power, for serial communications, and for data collection and reporting.

  • Page 16: Analog Out

    Getting Started Teledyne API – Model 430 Compact Ozone Analyzer 2.3.2. ANALOG OUT Connect a strip chart recorder or data-logger to the ANALOG OUT channels port. Configure the Analog Outputs via the Data menu (refer to Figure 3-2). Table 2-1. Analog Output Pin Assignments...

  • Page 17: Serial Communications

    2.3.4.1. COMMAND FORMAT AND SUMMARY For serial communications protocol, the Model 430 follows the generic command format, [cmd]: [val] where [cmd] is the command letter and [val] is the numerical value if needed. Refer to Table 2-3 for the command summary.

  • Page 18: Operation

    Operation Teledyne API – Model 430 Compact Ozone Analyzer OPERATION This section provides instructions for operating the Model 430, including a description of the display and control/navigation panel, the menu structure, and communication and data collection. 3.1. DISPLAY AND NAVIGATION At power on, a splash screen appears in the display, followed by measurement readings, which will stabilize after a short warming period.

  • Page 19: Figure 3-2. Model 430 Menu Map

    Teledyne API – Model 430 Compact Ozone Analyzer Operation Figure 3-2. Model 430 Menu Map 08311 DCN7342...

  • Page 20: View

    3.2.2. CAL (CALIBRATION) The Model 430 is calibrated at the factory to NIST traceable standards. A calibration certificate for your instrument is shipped with the instrument. Teledyne API also recommends that the Model 430 be re-calibrated once a year. Teledyne API can provide NIST traceable calibration services at our factory or on-site.

  • Page 21: Config (Configure)

    Teledyne API – Model 430 Compact Ozone Analyzer Operation 3.2.3. CONFIG (CONFIGURE) Scroll to the configuration parameters, press Enter to edit. Table 3-2. Config Menu Description Menu Item Description Filter Length Moving average filter for measured concentration (default 10 samples).

  • Page 22: Data

    Operation Teledyne API – Model 430 Compact Ozone Analyzer 3.2.4. DATA The Data menu allows configuration of the Analog Output and operation of the internal data log and the SD Card. Note that the menus use “NV” (non-volatile) to refer to data in the internal memory as distinguished from data on an SD card).

  • Page 23: Data Collection

    A new file is created daily at midnight. • SD cards are not provided with the instrument. • The Model 430 is compatible with SD and SDHC memory cards. The following brands are recommended: • SanDisk (SDHC Class 4 or faster) •...

  • Page 24: Maintenance And Service

    4.2. SERVICE AND TROUBLESHOOTING The Model 430 requires little service other than being wiped down occasionally and following the maintenance schedule as presented in Section 4.1. However, in the rare instance that any fault may occur, the instrument will display messages that describe the cause of the fault.

  • Page 25: Warnings And Errors

    Teledyne API – Model 430 Compact Ozone Analyzer Maintenance and Service 4.2.1. WARNINGS AND ERRORS A Warning alerts the user to a non-critical fault while allowing operation to continue; an Error is a critical fault that prevents operation of the instrument until the cause has been resolved.

  • Page 26: Table 4-2. Hexadecimal-To-Binary Conversion

    Maintenance and Service Teledyne API – Model 430 Compact Ozone Analyzer Table 4-2. Hexadecimal-to-Binary Conversion 08311C DCN7342...

  • Page 27: Technical Assistance

    Teledyne API – Model 430 Compact Ozone Analyzer Maintenance and Service Table 4-3. Ozone Bench Status Byte (FW rev 1.06, not logged, displayed as S:xx during errors) Definition Front Panel Message Data stale bit, no new data, 1 = stale...

  • Page 28: Principles Of Operation

    The Model 430 ozone analyzer measures ozone using UV absorption to calculate the concentration of ozone flowing through the sample path. The Model 430 uses a mercury lamp constructed to emit UV light at 254nm wavelength. This light shines down a hollow quartz tube that is alternately filled with sample gas, then filled with gas scrubbed to remove ozone in order to achieve a stable and accurate measurement.
  • Page 29 Teledyne API – Model 430 Compact Ozone Analyzer Principles of Operation Figure 5-2. Model 430 Electronic Diagram 08311 DCN7342...

  • Page 30: Spare Parts List

    Spare Parts List Teledyne API – Model 430 Compact Ozone Analyzer SPARE PARTS LIST Due to the dynamic nature of part numbers, please consult with Note Technical Support before ordering spare parts. Call or email: Phone: 800-324-5190 Email: sda_techsupport@teledyne.com or access various service options on our website at http://www.teledyne-api.com/.
