OPERATION AND PARTS MANUAL
MODEL BPX
GASOLINE BACKPACK VIBRATOR
(HONDA GXH50UQXA GASOLINE ENGINE)
Revision #1 (08/28/17)
To find the latest revision of this
publication, visit our website at:
www.multiquip.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
PN: 14454

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BPX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MULTIQUIP BPX

Summary of Contents for MULTIQUIP BPX

  • Page 1 OPERATION AND PARTS MANUAL MODEL BPX GASOLINE BACKPACK VIBRATOR (HONDA GXH50UQXA GASOLINE ENGINE) Revision #1 (08/28/17) To find the latest revision of this publication, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES. PN: 14454...

  • Page 2: Proposition 65 Warning

    PAGE 2 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)

  • Page 3: Silicosis/Respiratory Warnings

    NIOSH/MSHA for the materials being used. BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 3...
  • Page 4 Set-Up ............. 15–17 Inspection .............. 18 Operation ............19–24 Maintenance ............ 25–28 Troubleshooting ............. 29 Explanation Of Code In Remarks Column..... 30 Suggested Spare Parts ......... 31 PAGE 4 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)
  • Page 5 Discount-Equipment.com is your online resource for commercial and industrial quality equipment sales and rentals. We sell worldwide for the brands Genie, Terex, Stihl, JLG, Multiquip, Mayco, Stone, Diamond Products, Airman, Mustang, Power Blanket. Locations: Florida (West Palm Beach) – 561-964-4949...

  • Page 6: Safety Information

    COULD result in DEATH or SERIOUS INJURY. CAUTION Indicates a hazardous situation which, if not avoided, COULD result in MINOR or MODERATE INJURY. NOTICE Addresses practices not related to personal injury. PAGE 6 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)
  • Page 7 „ NEVER leave the vibrator unattended. Turn off engine the manufacturer who shall confi rm that the machine is when unattended. in conformity with appropriate safety regulations. BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 7...
  • Page 8 Allow these parts to cool the ignition system. before servicing equipment. PAGE 8 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)

  • Page 9: Safety Information

    The label must remain with the engine for its entire life. If a replacement emission label is needed, please contact your authorized Honda Engine Distributor. BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 9...

  • Page 10: Specifications

    (225 × 274 × 353 mm) (L x W x H) Dry Net Weight (Engine) 12.1 lb. (5.5 kg) Operating Weight (Vibrator/Backpack) 31 lb. (14.1 kg) PAGE 10 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)

  • Page 11: Dimensions

    DIMENSIONS Figure 1. Vibrator Dimensions Table 2. Vibrator Dimensions Reference Dimension in. (mm) Letter 11.0 (280) 13.75 (349) 27.0 (686) BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 11...

  • Page 12: General Information

    Failure to read this manual may result in severe bodily harm and damage to the equipment. PAGE 12 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)

  • Page 13: Components

    7. Belt Guard — Prevents access to the pulleys and V-belt while the vibrator is running. DO NOT operate the vibrator with this cover removed. BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 13...

  • Page 14: Components

    OFF position stops the engine. 11. Fuel Valve Lever — Open to allow the flow of fuel, and close to prevent the flow of fuel. PAGE 14 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)

  • Page 15: Set-Up

    15¼ (39) 5.2 (2.4) 1700HD Steel (43) 15 (38) 6.4 (2.9) 2100HD Steel (54) 13¼ (34) 9.4 (4.3) 2600HD Steel (67) 13¼ (34) 13.4 (6.1) BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 15...
  • Page 16 6. Test run the motor and check head vibration. DO NOT run the vibrator in the air (not in concrete mix) for longer than 1–2 minutes. PAGE 16 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)

  • Page 17: Set-Up

    LOCTITE™ 271 MALE QUICK DISCONNECT FS SERIES VIBRATOR COUPLER FLEXIBLE HEAD SHAFT APPLY LOCTITE™ 271 VIBRATOR HEAD Figure 4. Flexible Head and Vibrator Head Connections BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 17...

  • Page 18: Inspection

    Table 6. Oil Type Season Temperature Oil Type Summer 25°C or Higher SAE 10W-30 Spring/Fall 25°C – 10°C SAE 10W-30/20 Winter 0°C or Lower SAE 10W-10 PAGE 18 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)

  • Page 19: Operation

    1. Move the engine fuel valve lever (Figure 8) to the ON position. Figure 10. Engine Choke Lever (Open) Figure 8. Engine Fuel Valve Lever (ON) BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 19...
  • Page 20 Figure 12. Engine ON/OFF Switch (ON) Place the throttle lever (Figure 13) in the UP position (TURTLE) to start the engine in IDLE mode. Figure 14. Starter Grip PAGE 20 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)
  • Page 21 Figure 17. 3. Adjust the shoulder straps for comfort, then lock the shoulder strap buckle (Figure 17). BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 21...
  • Page 22 (instead of concrete) for longer than two minutes will cause overheating of the bearings and premature head failure. PAGE 22 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)
  • Page 23 Figure 22. Fuel Valve Lever (OFF) Figure 20. Throttle (Turtle/Idle Position) 3. Place the ON/OFF switch located on the left strap to the OFF position (Figure 21). BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 23...

  • Page 24: Operation

    To quickly shut down the engine while the vibrator is in use, place the engine ON/OFF switch located on the left strap to the OFF position (Figure 21). Figure 24. ON/OFF Switch (OFF) PAGE 24 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)

  • Page 25: Maintenance

    (2) These items should be serviced by your service dealer, unless you have the proper tools and are mechanically proficient. Refer to the Honda shop manual for service procedures. (3) For commercial use, log hours of operation to determine proper maintenance intervals. BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 25...
  • Page 26 DO NOT overfill. 3. Reinstall the drain bolt with sealing washer and tighten securely. GAP: 0.024 - 0.028 in. (0.6 - 0.7 mm.) Figure 25. Spark Plug PAGE 26 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)
  • Page 27 3. Dip the element in clean engine oil and completely squeeze out the excess oil from the element (Figure 28). 4. Reinstall the foam element and air cleaner cover. BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 27...

  • Page 28: Maintenance

    This will prevent damage to soft cloth. the threads. „ Cover the unit and store in a clean, dry place. PAGE 28 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)

  • Page 29: Troubleshooting

    Fuel fi lter/lines clogged? Replace fuel fi lter. Fuel tank cap breather hole clogged? Clean or replace fuel tank cap. Air in fuel line? Bleed fuel line. BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 29...

  • Page 30: Explanation Of Code In Remarks Column

    “Remarks” Column. assembly/kit that can be purchased, or is not available for sale through Multiquip. PAGE 30 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)

  • Page 31: Suggested Spare Parts

    1....34150ZH7023 ..OIL ALERT UNIT 1....35480ZM7801 ..OIL LEVEL SWITCH NOTICE Part numbers on this Suggested Spare Parts list may supersede/replace the part numbers shown in the following parts lists. BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 31...
  • Page 32 NAMEPLATE AND DECALS ASSY. BP X MODEL SERIAL NO. P/N 14441 P/N 23803 PAGE 32 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)
  • Page 33 SERIAL PLATE, NON CE ............1 ... CONTACT MQ PARTS 4014 SCREW, 2-3/16" P-K 14441 DECAL, READ, PROTECTION, SMOKING, GUARD, GAS 23803 DECAL, GUARANTEED SOUND, 115 DB BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 33...
  • Page 34 VIBRATOR ASSY. NOTES: APPLY LOCTITE™242 PAGE 34 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)
  • Page 35 LOCTITE™242, BLUE, .5CC BOTTLE 14489 SCREW, FHSC 1/4"-28 X 5/8" 14432 ENGINE, HONDA GXH50UQXA 0300 B WASHER, FLAT SAE 5/16" 14445 STAND OFF, 10-32 X 2.50LG BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 35...
  • Page 36 FRAME AND SWIVEL ASSY. SLEEVE NOTES: TUBE FRAME, ITEM 13 INCLUDES SLEEVE. SLEEVE CANNOT BE PURCHASED SEPARATELY. APPLY LOCTITE™242 PAGE 36 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)
  • Page 37 WASHER, FLAT USS 3/8" PLD. 14443 CLAMP, FRAME 3/4" 14467 SCREW, BHC 1/4"-20 X 1-1/2" 14431 TUBE, FRAME ...........1....SLEEVE CANNOT BE SOLD SEPARATELY 1477 LOCTITE™242, BLUE, .5CC BOTTLE BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 37...
  • Page 38 ENGINE MOUNTING ASSY. NOTES: 1 APPLY LOCTITE™242 2 TORQUE TO 68 IN-LB (7.68 N●M) PAGE 38 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)
  • Page 39 NUT, HEX JAM 1/4"-28 1477 LOCTITE™242, BLUE, .5CC BOTTLE 42542 SCREW HFS, ZP, M6-1.0 X 16 34308 SCREW, HHF SLOT, #10-32 X 5/8" 16576891000 HOLDER, CABLE BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 39...
  • Page 40 ENGINE SERVICE PARTS ASSY. PAGE 40 — BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17)
  • Page 41 CAP, FUEL 9805655777 SPARK PLUG (NKG) 34150ZH7023 OIL ALERT UNIT 35480ZM7801 OIL LEVEL SWITCH ASSY. 28462ZM70003 ROPE, STARTER 28461ZM3003 KNOB, RECOIL STARTER 17211ZM7000 ELEMENT, AIR BPX GASOLINE VIBRATOR • OPERATION AND PARTS MANUAL — REV. #1 (08/28/17) — PAGE 41...
