OPERATION MANUAL
SERIES
MODEL MVCi60
ONE - WAY PLATE COMPACTOR
(BATTERY ONE BOB10/BOB14
RECHARGEABLE BATTERY)
Revision #0 (11/12/24)
To find the latest revision of this publication or
associated parts manual, visit our website at:
www.multiquip.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mikasa Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MULTIQUIP Mikasa Series

Summary of Contents for MULTIQUIP Mikasa Series

  • Page 1 MODEL MVCi60 ONE - WAY PLATE COMPACTOR (BATTERY ONE BOB10/BOB14 RECHARGEABLE BATTERY) Revision #0 (11/12/24) To find the latest revision of this publication or associated parts manual, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

  • Page 2: Proposition 65 Warning

    PROPOSITION 65 WARNING PAGE 2 — MVCi60 COMPACTOR • OPERATION MANUAL — REV. #0 (11/12/24)

  • Page 3: Table Of Contents

    TABLE OF CONTENTS MVCi60 Plate Compactor Proposition 65 Warning ........... 2 Safety Information ..........4-6 Specifications ............8-9 Dimensions ............10 General Information ..........11 Components ............. 12-13 Inspection ............14-16 Operation ............17-18 Transportation and Storage ........19 Maintenance ............20 Troubleshooting .............

  • Page 4: Safety Information

    SAFETY INFORMATION Do not operate or service the equipment before reading Potential hazards associated with the operation of this the entire manual. Safety precautions should be followed equipment will be referenced with hazard symbols which at all times when operating this equipment. may appear throughout this manual in conjunction with Failure to read and understand the safety safety messages.
  • Page 5 „ NEVER use accessories or attachments that are not „ NEVER operate this equipment when not recommended by Multiquip for this equipment. Damage feeling well due to fatigue, illness or when to the equipment and/or injury to user may result.
  • Page 6 SAFETY INFORMATION COMPACTOR SAFETY NOTICE DANGER „ Before lifting, make sure that the equipment parts (hook and vibration insulator) are not damaged and screws are „ NEVER operate the equipment in an explosive not loose or missing. atmosphere or near combustible materials. An explosion or fi re could result causing severe „...
  • Page 7 NOTES MVCi60 COMPACTOR • OPERATION MANUAL — REV. #0 (11/12/24) — PAGE 7...

  • Page 8: Specifications

    SPECIFICATIONS Table 1. MVCi60 Specifications Centrifugal Force 2,473 lbf (11 kN) Vibration Frequency 5880 vpm (98 Hz) Max Traveling Speed 82 ft/min (25 m/min) Max. Area of Compaction 7,266 ft /hr (675 m /hr) Plate Size (L x W) 23 x 13.8 in (585 x 350 mm) Rated Operating Time 80 min (BOB10), 110 min (BOB14) Operating Weight...
  • Page 9 SPECIFICATIONS Table 4. Battery Charger Specifications Model Battery One BOC13 Dimensions (L x Wx H) 11.7 x 15.6 x 8.5 in (296 x 396 x 217 mm) Weight 11.7 lbs. (5.3 kg) Cable Length 78.7 in (2000 mm) Rated Voltage 100-240 VAC Rated Current 2.9 - 7.3 A...

  • Page 10: Dimensions

    DIMENSIONS Figure 1. MVCi60 Dimensions Table 6. Dimensions Reference Description Measurement Height 23.4 in (595 mm) Height (including handle) 39.8 in (1010 mm) Length of Plate 23 in (585 mm) Length of Plate (including stowed handle) 28.5 in. (725 mm) Length of Plate (including deployed handle) 41.5 in (1055 mm) Width of Plate...

  • Page 11: General Information

    GENERAL INFORMATION DEFINITION OF PLATE COMPACTOR VIBRATORY PLATES The Mikasa MVCi60 is a walk-behind, one-way plate The vibratory plates produce low amplitude high frequency compactor designed for the compaction of sand, mixed soils vibrations, designed to compact granular soils and asphalt. and asphalt.

  • Page 12: Components

    COMPONENTS Figure 2. MVCi60 Controls and Components PAGE 12 — MVCi60 COMPACTOR • OPERATION MANUAL — REV. #0 (11/12/24)
  • Page 13 COMPONENTS Figure 2 shows the location of the basic controls and 11. Lock for Wheel Kit — Locks the wheel kit in place. components of the MVCi60 Plate Compactor. The function 12. Guard Frame — Protects unit from being hit by other of each control is described below: objects.

  • Page 14: Inspection

    INSPECTION BEFORE STARTING BATTERY INSTALLATION NOTICE 1. Read safety instructions at the beginning of manual. Make sure to use a genuine rechargeable battery. 2. Clean the compactor, removing dirt and dust. Connections and contact area of the rechargeable 3. Check fastening nuts and bolts for tightness. Loosened battery must be clean and dry.
  • Page 15 INSPECTION Refer to Figure 4 for location of parts. WHEEL KIT CHECK HANDLE 1. Check that the lock for the wheel kit works. See Figure RECHARGEABLE BATTERY ON/OFF SWITCH GUIDE RAIL PULL THE KNOB AND TURN TO THE LEFT TO UNLOCK KNOB LOCK LOCK FOR WHEEL KIT...
  • Page 16 INSPECTION WATER TANK CHECK 3. Check that the wheels turn smoothly when unit is moved forward and backward. See Figure 8. 1. Check the water tank for leaks after filling up with water (Figure 9). 1. PULL BACK HANDLE UNTIL THE VIBRATING PLATE LEAVES THE GROUND 2.

  • Page 17: Operation

    OPERATION CAUTION CAUTION Failure to understand the operation of the plate • DO NOT use this machine on ground that is harder compactor could result in severe damage to the unit than the machine can handle, or for driving pilings or personal injury.
  • Page 18 OPERATION WATER TANK 1. If your application requires sprinkling work, open the valve of water tank (Figure 13). Figure 13. Water Tank Valve (Open) 2. When stopping sprinkling work, close the valve of water tank (Figure 14). Figure 14. Water Tank Valve (Close) PAGE 18 —...

  • Page 19: Transportation And Storage

    TRANSPORTATION AND STORAGE TRANSPORTATION 1. Stop the motor unit before transporting the machine. 2. Do not move the machine until the motor and main body have cooled down enough. 3. Remove the rechargeable battery. 4. Maintain upright position of the rammer on a level ground during transporting.

  • Page 20: Maintenance

    MAINTENANCE CAUTION Table 8. Tightening Torque (kg cm) Inspection and other services should always be carried out on hard and level ground with the engine shut down. Diameter Material 10mm 12mm 14mm 16mm 18mm 20mm INSPECTION AND MAINTENANCE TABLES 1,100 1,400 2,000 To make sure your plate compactor is always in good...

  • Page 21: Troubleshooting

    TROUBLESHOOTING Troubleshooting (Compactor) Symptom Possible Problem Solution Battery is not installed correctly? Reinstall battery. Battery charge is low? Fully charge battery. Exciter (vibrating motor does not start) Battery malfunction? Replace battery. Exciter broken? Replace exciter. NOTICE For Troubleshooting information of the Rechargeable Battery and Battery Charger, please refer to corresponding operation manual accompanying the product.

  • Page 22: Here's How To Get Help

    © COPYRIGHT 2024, MULTIQUIP INC. Multiquip Inc , the MQ logo are registered trademarks of Multiquip Inc. and may not be used, reproduced, or altered without written permission. All other trademarks are the property of their respective owners and used with permission.

This manual is also suitable for:

Mvci60

Table of Contents
