INSTRUCTION MANUAL
Model No:
DA036SECUK - GREY
Sectional
DA036SEC-BLUK - BLUE
DA036SEC-BGUK - BEIGE
Sofa
UPC CODE:
5060669113836
5060669113850
5060669113843
NOTE:
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
Lot number:
(LOCATED ON CARTON)
_____________________________________
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE RETAILER
If a part is missing or damaged, contact our customer
service department. We will replace the part
Free of charge.
Tel #: 01942 524100
AN
Email: cseurope@dorel.com
Advertisement
Table of Contents
Related Manuals for Dorel DA036SECUK
Summary of Contents for Dorel DA036SECUK
- Page 1 INSTRUCTION MANUAL Model No: DA036SECUK - GREY Sectional DA036SEC-BLUK - BLUE DA036SEC-BGUK - BEIGE Sofa UPC CODE: 5060669113836 5060669113850 5060669113843 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (LOCATED ON CARTON)
-
Page 2: Customer Service
Use a professional cleaning service to clean the fabric. 1-YEAR LIMITED WARRANTY Dorel warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase from authorized retailers. -
Page 3: Parts List
SECTIONAL SOFA DA036SECUK / DA036SEC-BLUK / DA036SEC-BGUK PARTS LIST BACK SEAT PANEL 1 PC 1 PC FRONT RAIL LEFT ARM 1 PC 1 PC RIGHT ARM SEAT CUSHION 1 PC 2 PCS BACK CUSHION SUPPORT LEG 3 PCS 1 PC... - Page 4 SECTIONAL SOFA DA036SECUK / DA036SEC-BLUK / DA036SEC-BGUK STEP 1 Place all parts on a clean, smooth surface. Attach front rail (C) to right arm (E) and left arm (D) by inserting the brackets on front rail (C) into the metal plate on left and right arms (D & E) as shown below.
- Page 5 SECTIONAL SOFA DA036SECUK / DA036SEC-BLUK / DA036SEC-BGUK STEP 2 Attach support leg ( H ) to seat panel (B) by rotating clockwise. NOTE: remove the protective cap on support leg (H) before beginning assembly. Back...
- Page 6 SECTIONAL SOFA DA036SECUK / DA036SEC-BLUK / DA036SEC-BGUK STEP 3 Attach seat panel (B) to left arm (D) and right arm (E) by inserting the metal brackets on seat panel (B) into the metal glides on left arm (D) and right arm (E).
- Page 7 SECTIONAL SOFA DA036SECUK / DA036SEC-BLUK / DA036SEC-BGUK STEP 4 Attach sofa back (A) to left and right arms (D & E) by inserting the brackets on sofa back (A) into the metal glides on left and right arms (D & E).
- Page 8 SECTIONAL SOFA DA036SECUK / DA036SEC-BLUK / DA036SEC-BGUK STEP 5 Attach foot (K) to ottoman (J) as shown below. Turn the ottoman (J) upright and place it in front of the assembled sofa. NOTE: remove the protective cap on foot (K) before beginning assembly.
- Page 9 SECTIONAL SOFA DA036SECUK / DA036SEC-BLUK / DA036SEC-BGUK STEP 6 Place the cushion (F , G & I) onto the sofa. NOTE:The cushions have been vacuum packed for transportation purposes. After unpacking, please allow up to 72 hours so that they can return...
- Page 10 SECTIONAL SOFA DA036SECUK / DA036SEC-BLUK / DA036SEC-BGUK CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury.
